Pure Titanium Wire 2.4mm

Product Details

Place of Origin: China

Brand Name: LHTI

Certification: ISO9001:2015; TUV; SGS;BV

Model Number: LH-12

Payment & Shipping Terms

Minimum Order Quantity: 10 kg

Packaging Details: Coil and spool package in carton case or plywood case,straight wire package in Plastic case,outside is standard export plywood case

Delivery Time: In stock--3 days.production--15-20 working days

Payment Terms: L/C, D/P, T/T, Western Union,paypal etc

Supply Ability: 50000 kgs per month

Get Best Price
Highlight:
Product Name:
ERTi 1 ERTi 2 Gr.1 Gr.2 Straight / Coil Ti Pure Titanium Wire Price
Grade:
Grade1 Grade2 ErTi1 ErTi2
Shape:
Coil,spool,straight
Material:
Pure Titanium
Surface:
Pickling Surface/polish Surface
Package:
Standard Export Package
Hot Sale Diameter:
0.8mm-5mm Etc
Length:
1000mm
Key Words:
Thin Titanium Wire
Product Name:
ERTi 1 ERTi 2 Gr.1 Gr.2 Straight / Coil Ti Pure Titanium Wire Price
Grade:
Grade1 Grade2 ErTi1 ErTi2
Shape:
Coil,spool,straight
Material:
Pure Titanium
Surface:
Pickling Surface/polish Surface
Package:
Standard Export Package
Hot Sale Diameter:
0.8mm-5mm Etc
Length:
1000mm
Key Words:
Thin Titanium Wire
Pure Titanium Wire 2.4mm

Pure Titanium Wire 2.4mm



ASME SFA 5.16 Titanium Wire has a metallic luster and is malleable. Its main characteristics are low density, high mechanical strength and easy processing, meanwhile, it has good corrosion resistance and is not affected by the atmosphere and seawater. It also has good machinability, making the operation easy and labor-saving. Also, it is available with a vatiety of specifications, able to cover your various applying needs.



Features

ASME SFA 5.16 Titanium Wire is processed through high-precision machines, achieving high durability and accuracy. Titanium is a non-magnetic metal, which can effectively avoid interference and is widely used in railroad engineering, communication, aerospace, high-tech laboratories, hospitals, outdoor work, chemical industry, seawater nitriding, etc. Titanium also has small thermal conductivity and high damping resistance.



ASTM Base Metal Grade Base metal Normal composition Recommended Filler Metal
  UTS(min.) ksi[Mpa] YS(min.) ksi[Mpa]
Grade 1 35[240] 20[138] Unalloyed Ti CP1 ERTi-1
Grade 2 50[345] 40[275] Unalloyed Ti CP2 ERTi-2
Grade 4 80[550] 70[483] Unalloyed Ti CP4 ERTi-4
Grade 5 130[895] 120[828] Ti 6AL-4V ERTi-5
Grade 7 50[345] 40[275] Ti 0.15Pd ERTi-7



AWS CHEMICAL SPECIFICATIONS
AWS A5.16 UNS C O N H I Al V Pd
  Number
ERTi 1 R50100 0.03 0.03-0.10 0.012 0.005 0.08 - - -
ERTi 2 R50120 0.03 0.08-0.16 0.015 0.008 0.12 - - -
ERTi 4 R50130 0.03 0.08-0.32 0.025 0.008 0.25 - - -
ERTi 5 R56400 0.05 0.12-0.20 0.03 0.015 0.22 5.5-6.7 3.5-4.5 -
ERTi 7 R52401 0.03 0.08-0.16 0.015 0.008 0.12 - - 0.12-0.25
