Home > products > Titanium Wire > ASTM F136/F1341 Pure Titanium Wire Titanium TI-6AL-4V Weld Wire

ASTM F136/F1341 Pure Titanium Wire Titanium TI-6AL-4V Weld Wire

Product Details

Place of Origin: China

Brand Name: LHTI

Certification: ISO9001:2015; TUV; SGS;BV

Model Number: LH-12

Payment & Shipping Terms

Minimum Order Quantity: 10 kg

Packaging Details: Coil and spool package in carton case or plywood case,straight wire package in Plastic case,outside is standard export plywood case

Delivery Time: In stock--3 days.production--15-20 working days

Payment Terms: L/C, D/P, T/T, Western Union,paypal etc

Supply Ability: 50000 kgs per month

Get Best Price
Highlight:
Product Name:
ERTi 1 ERTi 2 Gr.1 Gr.2 Straight / Coil Ti Pure Titanium Wire Price
Grade:
Grade1 Grade2 ErTi1 ErTi2
Shape:
Coil,spool,straight
Material:
Pure Titanium
Surface:
Pickling Surface/polish Surface
Package:
Standard Export Package
Hot Sale Diameter:
0.8mm-5mm Etc
Length:
1000mm
Key Words:
Thin Titanium Wire
Product Name:
ERTi 1 ERTi 2 Gr.1 Gr.2 Straight / Coil Ti Pure Titanium Wire Price
Grade:
Grade1 Grade2 ErTi1 ErTi2
Shape:
Coil,spool,straight
Material:
Pure Titanium
Surface:
Pickling Surface/polish Surface
Package:
Standard Export Package
Hot Sale Diameter:
0.8mm-5mm Etc
Length:
1000mm
Key Words:
Thin Titanium Wire
ASTM F136/F1341 Pure Titanium Wire Titanium TI-6AL-4V Weld Wire

Pure Titanium Wire Titanium TI-6AL-4V Weld Wire



ASTM F136/F1341 Pure Titanium Wire is annealed and polished, meets medical ASTM F136 specifications. The grade 23 titanium alloy, also known as Ti 6Al-4V ELI, offers high toughness and moderate wear resistance, along with corrosion resistance, high strength, and good formability. The material has been annealed, a method of heating and cooling metal to modify its properties, such as increasing its formability and toughness or decreasing its strength, after it has been shaped.



Titanium and its alloys, due to a successful combination of high strength, sufficient technological properties, small density and good corrosion resistance are gaining wider application for medical instruments production, used in general surgery, stomatology, neurosurgery, otorhinolaryngology, ophthalmology etc. The application of titanium alloys for surgical implants, micro instruments and also sets of microsurgical instruments in combination with stainless steels is most expedient.



ASTM Base Metal Grade Base metal Normal composition Recommended Filler Metal
  UTS(min.) ksi[Mpa] YS(min.) ksi[Mpa]
Grade 1 35[240] 20[138] Unalloyed Ti CP1 ERTi-1
Grade 2 50[345] 40[275] Unalloyed Ti CP2 ERTi-2
Grade 4 80[550] 70[483] Unalloyed Ti CP4 ERTi-4
Grade 5 130[895] 120[828] Ti 6AL-4V ERTi-5
Grade 7 50[345] 40[275] Ti 0.15Pd ERTi-7



AWS CHEMICAL SPECIFICATIONS
AWS A5.16 UNS C O N H I Al V Pd
  Number
ERTi 1 R50100 0.03 0.03-0.10 0.012 0.005 0.08 - - -
ERTi 2 R50120 0.03 0.08-0.16 0.015 0.008 0.12 - - -
ERTi 4 R50130 0.03 0.08-0.32 0.025 0.008 0.25 - - -
ERTi 5 R56400 0.05 0.12-0.20 0.03 0.015 0.22 5.5-6.7 3.5-4.5 -
ERTi 7 R52401 0.03 0.08-0.16 0.015 0.008 0.12 - - 0.12-0.25
