Home Products

Titanium Tube

Gr9 Titanium Seamless Tubes Titanium Pipe

Name: Gr9 Titanium Seamless Tubes Titanium Pipe
Brand: Baoji Lihua Nonferrous Metals Co., Ltd.
SKU: Gr2 titanium round seamless pipe and tube
Price: 25.00 USD
Availability: InStock

Brand Name:	LH-Ti
Model Number:	Gr2 titanium round seamless pipe and tube
MOQ:	5 Kg
Price:	$20.00~$30.00/kg
Payment Terms:	L/C, T/T, MoneyGram,Paypal
Supply Ability:	10000 Kilogram/Kilograms per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Shaanxi, China

Certification:

ISO9001:2015

Standard:

ASTM

Technique:

Seamless, Cold Drawn

Processing Service:

Bending, Welding, Decoiling, Cutting, Punching

Material:

Titanium

Grade:

Titanium, Gr2 Gr5 Gr7 Gr9 Gr12

Application:

Industrial

Outer Diameter:

10-300mm

Inside Diameter:

4~268mm

Packaging Details:

First, packaging with moisture-proof paper; Second, packaging with kraft paper; Third, packaging with foam plastics in all side of plywood case.

Supply Ability:

10000 Kilogram/Kilograms per Month

Product Description

Gr9 Titanium Tubes For Titanium Bicycle Frame Titanium Pipe

Commodity:Gr9 Titanium Alloy Tube & Pipe
Standard:ASTM B338/SB861, ASTM SB338/SB861, EN10204
Material:Gr9,Ti3AL-2.5V
OD:1 1/2''- 24'' 48.3mm-609.6mm
WallThickness:1-50mm or as required
Length:6m, 11.8m, 4-12m or as required
Technique:Hot Rolled
Surface:Bright/pickling

The Gr9 Titanium Seamless Tubes have the advantages of corrosion resistance, high yield strength and density ratio, small thermal expansion coefficient, long service life, high heat transfer efficiency. Due to the high performance, it realizes the function to greatly improve the life of the titanium tube heat exchanger and reduce the loss caused by equipment failure due to corrosion failure, good economic benefits. As a matter of fact, it is widely used in petrochemical and other fields. Due to its high strength, light weight, good heat transfer and corrosion resistance, it can be an ideal facility used in chemical, petroleum, petrochemical, vacuum salt, desalination, power and other industries.

Chemical requirements
	N	C	H	Fe	O	Al	V	Pd	Mo	Ni	Ti
Gr1	0.03	0.08	0.015	0.20	0.18	/	/	/	/	/	bal
Gr2	0.03	0.08	0.015	0.30	0.25	/	/	/	/	/	bal
Gr5	0.05	0.08	0.015	0.40	0.20	5.5~6.75	3.5~4.5	/	/	/	bal
Gr7	0.03	0.08	0.015	0.30	0.25	/	/	0.12~0.25	/	/	bal
Gr12	0.03	0.08	0.015	0.30	0.25	/	/	/	0.2~0.4	0.6~0.9	bal

Tensile requirements
Grade	Tensile srength(min)		Yeild strength(mm)		Elongation(%)
	KSI	MPa	Ksi	MPa
1	35	240	20	138	24
2	50	345	40	275	20
5	130	895	120	828	10
7	50	345	40	275	20
12	70	438	50	345	18

Gr9 Titanium Seamless Tubes Titanium Pipe 0
