Product Details
Place of Origin: China
Brand Name: LHTi
Certification: ISO9001:2015;
Model Number: Titanium Plate
Payment & Shipping Terms
Minimum Order Quantity: 100 kg
Packaging Details: Plywood box with soft foam for additional protection
Delivery Time: 10-20 work days
Payment Terms: T/T, MoneyGram, L/C, Western Union
Supply Ability: 200000 kg per month
Standard: |
ASTM B265 |
Technology: |
Hot Rolled |
Shape: |
Straight |
Surface: |
Rolling Surface |
Use: |
Chemical |
Thicknes: |
15mm 20mm 25mm |
Product Name: |
TA2 GR2 Titanium Plate 15mm 20mm 25mm ASTM B265 |
Standard: |
ASTM B265 |
Technology: |
Hot Rolled |
Shape: |
Straight |
Surface: |
Rolling Surface |
Use: |
Chemical |
Thicknes: |
15mm 20mm 25mm |
Product Name: |
TA2 GR2 Titanium Plate 15mm 20mm 25mm ASTM B265 |
ASTM B265 GR2 Titanium Plate 15mm Thicknes Hot Rolled
1. Plate quality: GR5 titanium alloy plate
2. Specification: about 1000 length, 2000 width, and plate with thickness *1m*2m
3. Executive standard: AMS4911, etc.
4. Titanium plate features: low density, light texture, high temperature resistance, corrosion resistance, high tensile strength of titanium alloy plate, good mechanical properties
5. Application: widely used in electric power, chemical industry, ship, military industry, aviation, medical treatment, electroplating, petroleum exploitation and other fields.
Titanium Ti6Al4V Plate For Aerospace has high strength and is not easily deformed and rusted. We have a full range of product specifications, affordable prices, reliable quality and fast delivery. It has good performance of wear-resisting and anti-corrosion. It has smooth surface, clear and burr-free. It has low density and high strength, making it an essential structural material for industrial production.
| Chemical requirements | |||||||||||
| N | C | H | Fe | O | Al | V | Pd | Mo | Ni | Ti | |
| Gr1 | 0.03 | 0.08 | 0.015 | 0.20 | 0.18 | / | / | / | / | / | bal |
| Gr2 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | / | / | / | bal |
| Gr5 | 0.05 | 0.08 | 0.015 | 0.40 | 0.20 | 5.5~6.75 | 3.5~4.5 | / | / | / | bal |
| Gr7 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | 0.12~0.25 | / | / | bal |
| Gr12 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | / | 0.2~0.4 | 0.6~0.9 | bal |
| Tensile requirements | |||||
| Grade | Tensile srength(min) | Yeild strength(mm) | Elongation(%) | ||
| KSI | MPa | Ksi | MPa | ||
| 1 | 35 | 240 | 20 | 138 | 24 |
| 2 | 50 | 345 | 40 | 275 | 20 |
| 5 | 130 | 895 | 120 | 828 | 10 |
| 7 | 50 | 345 | 40 | 275 | 20 |
| 12 | 70 | 438 | 50 | 345 | 18 |
