Product Details
Place of Origin: China
Brand Name: LHTI
Model Number: LHTI-4
Payment & Shipping Terms
Minimum Order Quantity: 20kg
Price: USD20-50 per kg
Packaging Details: export wooden box packaging
Delivery Time: 7-30work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5Ton per month
Technique: |
Cold Rolled |
Shape: |
Plate, Sheet |
Melting Point: |
1678℃ |
Finishing: |
Pickling, Machining, Abrasive Blasting |
Application: |
Industry,Aeroplane, Surgical Plant, Etc. |
Density: |
About 4.51g/cm3 |
Technique: |
Cold Rolled |
Shape: |
Plate, Sheet |
Melting Point: |
1678℃ |
Finishing: |
Pickling, Machining, Abrasive Blasting |
Application: |
Industry,Aeroplane, Surgical Plant, Etc. |
Density: |
About 4.51g/cm3 |
Titanium Plate Property
Titanium plate and titanium have the same natural properties.
Its feature :light weight, high strength, metallic luster, and good corrosion resistance.
Titanium plate standard
China Standard : GB / T3621-2007, GB / T13810-2007,
USA Standard: ASTM B265, ASTM F136, ASTM F67,
(AMS4911 is Ti-6AI-4V annealed titanium alloy plate, sheet and strip)
titanium plate Specification
Common size:
T 0.5-5.0mm x W1000mm x L 2000-3500mm
T 5.0- 30mm x W1000-2500mm x L 3000-6000mm
T 30- 80mm x W1000mm x L 2000mm
titanium plate status
Annealed state (M) Hot-worked state (R) Cold-worked state (Y)
titanium plate surface
Pickled surface/ Bright surface/ Sandblasted surface
titanium plate application
Metallurgy, electronics, medical, chemical, petroleum, medicine, aerospace, etc.
Chemical requirements of titanium plate
| N | C | H | Fe | O | Al | V | Pa | Mo | Ni | Ti | |
| Gr 1 | 0.03 | 0.08 | 0.015 | 0.20 | 0.18 | / | / | / | / | / | bal |
| Gr 2 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | / | / | / | bal |
| Gr 3 | 0.05 | 0.08 | 0.015 | 0.30 | 0.35 | / | / | / | / | / | bal |
| Gr 4 | 0.05 | 0.08 | 0.015 | 0.50 | 0.40 | / | / | / | / | / | |
| Gr 5 | 0.05 | 0.08 | 0.015 | 0.40 | 0.20 | 5.5~6.75 | 3.5~4.5 | / | / | / | bal |
| Gr 7 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | 0.12~0.25 | / | / | bal |
| Gr 9 | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 2.5~3.5 | 2.0~3.0 | / | / | / | bal |
| Gr12 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | / | 0.2~0.4 | 0.6~0.9 |
bal |
