Gr2 Gr5 Gr7 Titanium Plate Sheet Cold Rolled For Industry

Brand Name:	LHTI
Model Number:	LHTI-027
MOQ:	100kg
Price:	USD15-65 per kg
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	5Ton per month

Detail Information

Product Description

Detail Information

Place of Origin:

Baoji City Shaanxi Province China

Certification:

ISO9001

Technique:

Cold Rolled

Shape:

Plate, Sheet

Melting Point:

1678℃

Finishing:

Pickling, Machining, Abrasive Blasting

Application:

Industry,Aeroplane, Surgical Plant, Etc.

Density:

About 4.51g/cm3

Standard:

ASTM B265

Material:

GR1 GR2 GR5 GR7 GR12

Packaging Details:

export wooden box packaging

Supply Ability:

5Ton per month

Highlight:

Gr7 Cold Rolled Titanium Sheet

Gr7 Titanium Plate

Industry Lightweight Titanium Plate

Product Description

Gr2 Gr5 Gr7 Titanium Plate Sheet

1. Specifications:

Titanium Plate Property

Titanium plates and titanium have the same natural properties.

Its features: lightweight, high strength, metallic luster, and good corrosion resistance.

Titanium plate standard

China Standard : GB / T3621-2007, GB / T13810-2007,

USA Standard: ASTM B265, ASTM F136, ASTM F67,

(AMS4911 is Ti-6AI-4V annealed titanium alloy plate, sheet, and strip)

titanium plate Specification

Common size:

T 0.5-5.0mm x W1000mm x L 2000-3500mm

T 5.0- 30mm x W1000-2500mm x L 3000-6000mm

T 30- 80mm x W1000mm x L 2000mm

Product name type	Titanium plate/Titanium sheet
Titanium Type	pure titanium
Titanium Grade	Gr1 Gr2 Gr5 Gr7 Gr12
Width	50-3000mm
Length	Cut available
Technique	Hot Rolled & Cold Rolled
Thickness	0.3~100mm
Shape	Plate/Coil
Standard	ASTM B265 / ASME 265/ AMS 4911 /ASTM F67 / ASTM F136/ISO 5832-2 / ISO 5832-3
Condition	R(Hot Working) Y(Cold Working) M(Annealed)
Application	electrolysis

Product name	Gr2 Gr12 titanium plate/Ti-0.2Pd
Material grade	Gr1, Gr2, Gr4, Gr5,Gr7, Gr9, Gr23, TI-6Al4v,
Certificate	ISO9001:2008, TUV, material test certificate EN10204.3.1
Standard	ASTM B265,ASME SB265,AMS4911,ASTM F136,ASTM F67
Technique	Hot/cold rolled
Surface	Acid wash, polished
Dimensions	Thickness:0.3-100mm
	Width:20-1220mm
	Length:500-6000mm

Application:(Titanium plate)

1. Heat exchangers and condensers
2. Seawater desalination industry
3. Chemical Industry,
4. Electroplating equipment
5. Precision instruments
6. Environmental protection equipment
7. Auto industry
8. Medical and Sports industry
9. Electric power industry

2. Product Description

Gr2 Gr5 Gr7 Titanium Plate Sheet Cold Rolled For Industry 0

3. Chemical requirements

Chemical requirements of titanium plate

	N	C	H	Fe	O	Al	V	Pa	Mo	Ni	Ti
Gr 1	0.03	0.08	0.015	0.20	0.18	/	/	/	/	/	bal
Gr 2	0.03	0.08	0.015	0.30	0.25	/	/	/	/	/	bal
Gr 3	0.05	0.08	0.015	0.30	0.35	/	/	/	/	/	bal
Gr 4	0.05	0.08	0.015	0.50	0.40	/	/	/	/	/
Gr 5	0.05	0.08	0.015	0.40	0.20	5.5~6.75	3.5~4.5	/	/	/	bal
Gr 7	0.03	0.08	0.015	0.30	0.25	/	/	0.12~0.25	/	/	bal
Gr 9	0.03	0.08	0.015	0.25	0.15	2.5~3.5	2.0~3.0	/	/	/	bal
Gr12	0.03	0.08	0.015	0.30	0.25	/	/	/	0.2~0.4	0.6~0.9	bal
