ASTM B338 Titanium Tube Grade 1/2 Pickling Surface Titanium Pipe EB1199

Brand Name:	LHTI
Model Number:	LH-01
MOQ:	1kg of each size
Price:	US dollar $23/kg-US dollar $31/kg
Payment Terms:	L/C, D/P, T/T, Western Union,Paypal.etc
Supply Ability:	5 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

BaoJi Shaanxi China

Certification:

ISO9001

Key Words 1:

Titanium Tube

Key Words 2:

GR2 Titanium Straight Tube

Key Words 3:

Titanium Pipe

Material:

Pure Titanium

Grade:

Grade 2

Purity:

99.5%min

Length:

1000mm In Stock

Surface:

Pickling Surface

Application:

Industrial

Production Time:

3 Working Days

Payment Term:

T/T,Paypal,Western Union Etc

Packaging Details:

Each tube with environmental protection bags,outside is standard plywood case

Supply Ability:

5 tons per month

Highlight:

ndustrial Titanium Pipe 1mm

ASTM B338 Titanium Pipe

Pickling Surface Titanium Tube

Product Description

High Quality Titanium Tube,ASTM B338 Titanium Pipes,Grade 1/2 Titanium Pipe EB1199

Material: pure Titanium (Gr2)

Tubing Size:1.5"(38.1mm)/2.0"(50.8mm)/2.5"(63.5mm) 3" (76.2mm)/3.5"(88.9mm)/4.0"(101.6mm) etc

Tubing Length: 39.4 Inches (1.0 Meters)
Wall Thickness: 1mm / .039" /1.2mm

Style: Seamless/welding

Surface: pickling surface/polish surface etc

Chemical requirements
	N	C	H	Fe	O	Al	V	Pd	Mo	Ni	Ti
Gr1	0.03	0.08	0.015	0.20	0.18	/	/	/	/	/	bal
Gr2	0.03	0.08	0.015	0.30	0.25	/	/	/	/	/	bal
Gr5	0.05	0.08	0.015	0.40	0.20	5.5~6.75	3.5~4.5	/	/	/	bal
Gr7	0.03	0.08	0.015	0.30	0.25	/	/	0.12~0.25	/	/	bal
Gr12	0.03	0.08	0.015	0.30	0.25	/	/	/	0.2~0.4	0.6~0.9	bal

Tensile requirements
Grade	Tensile srength(min)		Yeild strength(mm)		Elongation(%)
	KSI	MPa	Ksi	MPa
1	35	240	20	138	24
2	50	345	40	275	20
5	130	895	120	828	10
7	50	345	40	275	20
12	70	438	50	345	18
