Grade 2 Corrosion Resistant Titanium Tube and Pipe for Heat Exchanger Applications

Name: Grade 2 Corrosion Resistant Titanium Tube and Pipe for Heat Exchanger Applications
Brand: Baoji Lihua Nonferrous Metals Co., Ltd.
SKU: Titanium Tube
Price: 22,906.00 USD
Availability: InStock

Brand Name:	LHTi
Model Number:	Titanium Tube
MOQ:	100 pieces
Price:	negotiable
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	200-300 Ton/Tons Per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Baoji, China

Certification:

ISO9001,CE, API,etc

Factory Area:

3000 ㎡

Packing:

Standard Exported Wooden Cases

Refrigerant:

R22,R134a,R407c,R410a R417a

Key Words:

Thick Wall Titanium Alloy Tube

Payment Term:

T/T,L/C Etc

Corrosionresistance:

Excellent

Heat Resistance:

High

Meltingpoint:

1660℃

Dimention:

OD(5-114)X(0.3—10)XL1200mmMax

Melting Point:

1668 °C

Inner Diameter:

Customized

Application:

Aerospace, Medical, Chemical Industry

Situation:

Annealed

Grade:

Grade 2

Tolerance:

±0.05mm

Packaging Details:

All goods are packed by seaworth shipment materials or required by buyer

Supply Ability:

200-300 Ton/Tons Per Month

Highlight:

Ti Gr1 Manufacturing Processes Titanium Tube

Gr5 Titanium Tube

Gr2 Heat Exchangers Titanium Tube

Product Description

Titanium Tubes and Pipes for Heat Exchangers & Industrial Applications

Titanium tubes and pipes in Grades 1, 2, and 5 offer exceptional performance for heat exchangers and industrial applications. These materials provide superior corrosion resistance, strength-to-weight ratio, and durability in demanding environments.

Titanium Grade Classification

Grade 1 Titanium (Commercially Pure)

Composition: 99% pure titanium with minimal iron, oxygen, and nitrogen

Key Properties:

Excellent corrosion resistance
High ductility and formability
Easy welding and processing
Superior performance in reducing environments and seawater

Applications: Marine heat exchangers, pharmaceutical and food processing piping, medical implants

Grade 2 Titanium (Commercially Pure)

Composition: Similar to Grade 1 with slightly higher oxygen content

Key Properties:

Enhanced strength compared to Grade 1
Excellent corrosion resistance
Good weldability and formability

Applications: Chemical processing heat exchangers, systems handling chlorine and sulfuric acid, seawater desalination systems

Grade 5 Titanium (Ti-6Al-4V Alloy)

Composition: 90% titanium, 6% aluminum, 4% vanadium

Key Properties:

High strength with moderate corrosion resistance
Excellent fatigue and creep resistance
Reduced ductility compared to pure grades

Applications: Aerospace components, high-pressure heat exchangers, automotive applications, gas processing plants

Key Properties and Benefits

Corrosion Resistance: Exceptional performance in aggressive environments including chlorides, acids, and alkalines

Strength and Weight: Superior strength-to-weight ratio, particularly in Grade 5 alloys

High-Temperature Resistance: Maintains structural integrity at elevated temperatures for power plants and chemical reactors

Industrial Applications

Heat Exchangers: Chemical reactors, power plants, and marine environments requiring corrosion resistance and efficient heat transfer

Marine and Seawater Desalination: Superior saltwater corrosion resistance for cooling systems and desalination plants

Chemical Processing: Systems handling aggressive chemicals including chlorine, hydrochloric acid, and sulfuric acid

Aerospace and Automotive: Structural components, exhaust systems, and heat exchangers requiring lightweight high-strength materials

Medical and Pharmaceutical: Biocompatible equipment for mixing tanks, piping systems, and pharmaceutical processes

Technical Specifications

Item	Standard	Material	Size (mm)
Heat Exchanger and Condenser Tube	ASTM B338, B337, B861	Grade 1, 2, 3	OD (5-114) × (0.3-10) × L 12000mm Max
Corrosion Resistant Tubes	ASTM B338	Grade 7, Grade 12	OD (5-114) × (0.5-4.5) × Length 12000mm Max
Bike Frame/Wheelchair/Exhaust Tube/Pipes	ASTM B338	Gr9/Ti3Al2v5	OD (38.1-44.5) × (0.9-3.15) × (L 1000-2000mm)
Automobile & Motorcycle Exhaust Tube/Pipes	ASTM B337/338	Gr1, Gr2, Gr9	OD (38.1-88.9) × 1.2 × (L 1000-2000mm)
Marine Industry	ASTM/AMS	Gr2, Gr5, Gr7, Gr12	OD (23.1-210) × (W 0.5-6.0) × (L 1000-6000mm)

Summary: Grade 1 for corrosion resistance in marine and pharmaceutical applications; Grade 2 for chemical processing and harsh environments; Grade 5 for high-strength applications in aerospace and high-pressure systems.
