Titanium Tube GR1 GR2 GR5 And GR7

Titanium Tube GR1 GR2 GR5 And GR7

Brand Name:	LHTi
Model Number:	LH-bar
MOQ:	500kg
Price:	US dollar $25/pc--US dollar $28/pc
Payment Terms:	L/C,D/P,T/T,Western Union，paypal
Supply Ability:	5 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

Baoji, China

Certification:

ISO9001, TUV etc.

Model:

TP006

Company Staff:

Smls Or Welded:

Seamless

Thickness:

2mm

Elongation:

20%

Payment Term:

T/T,L/C Etc

Length:

Customizable

Yieldstrength:

800MPa

Specific Use:

Heating And Cooling

Material Grade:

Gr1,Gr2

Product Type:

Polished Welded Titanium Round Tubes

Classification:

Grade 9

Payment:

Corrosionresistance:

Excellent

Tensilestrength:

1000MPa

Packaging Details:

Wrapped by foam contained in plywood box for export

Supply Ability:

5 tons per month

Highlight:

GR5 Titanium Tube

GR2 Titanium Tube

GR7 Titanium Tube

Product Description

Titanium Tube GR1 GR2 GR5 And GR7 | Titanium Alloy Tube | Titanium Welded Tube

Titanium Alloy Bars for Every Application

Titanium alloys are essential materials in various industries due to their outstanding mechanical properties, corrosion resistance, and lightweight characteristics. Our titanium alloy bars in grades GR1, GR2, GR5, and GR7 are popular for diverse applications across aerospace, medical, and chemical industries.

Product Specifications

Name	Pure Titanium & Titanium Alloy Tube/Pipe/Tubing
Tube Shape	Round
Material	Gr1, Gr2
Standard	ASTM B338
SMLS Or Welded	Seamless (SMLS)
OD	19mm (1.25")/25.4mm, 38mm
Wall Thickness	1.2mm
Length	6m long
End	Plain End, Beveled End, Threaded

Chemical Composition (%)

Grade	N(%)	C(%)	H(%)	Fe(%)	O(%)	Ti	Other, max
1	≤0.03	≤0.08	≤0.015	≤0.20	≤0.18	Bal	≤0.4
2	≤0.03	≤0.08	≤0.015	≤0.30	≤0.25	Bal	≤0.4

Mechanical Properties

Grade	Tensile Strength(min)	Yield Strength(0.2% offset)	Elongation(%)
1	35 ksi / 240 MPa	15 ksi / 140 MPa	≥24
2	60 ksi / 400 MPa	40 ksi / 275 MPa	≥20

Certifications

EN 10204/3.1B
Raw Materials Certificate
100% Radiography Test Report
Third Party Inspection Report (TUV, BV, SGS etc)

Applications

Chemical Equipment
Sea Water Equipment
Heat Exchangers
Condensers
Pulp and Paper Industry
