Astm B348 Round Titanium Rod GR1 GR2 GR3 GR4 Pure Titanium Bar

Name: Astm B348 Round Titanium Rod GR1 GR2 GR3 GR4 Pure Titanium Bar
Brand: Baoji Lihua Nonferrous Metals Co., Ltd.
SKU: Titanium Rod
Price: 25.00 USD
Availability: InStock

Brand Name:	LHTi
Model Number:	Titanium Rod
MOQ:	30 kg
Price:	$20.00~$30.00/kg
Payment Terms:	T/T,MoneyGram,L/C,Western Union,Paypal
Supply Ability:	300000 kg per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001:2015; TUV; SGS;BV

Diameter:

3mm-350mm

Material:

Pure Titanium

Surface:

Bright,Polished,Pickling

Condition:

Annealed; M

MOQ:

30 Kg

Packing:

Standard Export Packing

Packaging Details:

Plywood box with soft foam for additional protection,Standard Export package Titanium bar/rod will be packed in the plastic first and then use wooden case,wooden case or according to your order.

Supply Ability:

300000 kg per month

Highlight:

GR4 Titanium Bar

Astm B348 Round Titanium Rod

Annealed Pure Titanium Bar

Product Description

ASTM B348 Round Titanium Rod - GR1, GR2, GR3, GR4 Pure Titanium Bar

Pure titanium round bars are cylindrical metal rods manufactured from corrosion-resistant, lightweight pure titanium. These bars offer exceptional strength and durability, making them ideal for demanding applications across aerospace, medical, and industrial sectors. Available in various sizes and diameters, they provide versatile solutions for aircraft components, medical implants, chemical processing equipment, and more. The material's excellent machinability and weldability allow for easy customization to meet specific project requirements.

Chemical Composition Requirements

Grade	N	C	H	Fe	O	Al	V	Pd	Mo	Ni	Ti
Gr1	0.03	0.08	0.015	0.20	0.18	/	/	/	/	/	bal
Gr2	0.03	0.08	0.015	0.30	0.25	/	/	/	/	/	bal
Gr5	0.05	0.08	0.015	0.40	0.20	5.5~6.75	3.5~4.5	/	/	/	bal
Gr7	0.03	0.08	0.015	0.30	0.25	/	/	0.12~0.25	/	/	bal
Gr12	0.03	0.08	0.015	0.30	0.25	/	/	/	0.2~0.4	0.6~0.9	bal

Tensile Requirements

Grade	Tensile Strength (min)	Yield Strength	Elongation (%)
1	35 KSI / 240 MPa	20 KSI / 138 MPa	24
2	50 KSI / 345 MPa	40 KSI / 275 MPa	20
5	130 KSI / 895 MPa	120 KSI / 828 MPa	10
7	50 KSI / 345 MPa	40 KSI / 275 MPa	20
12	70 KSI / 438 MPa	50 KSI / 345 MPa	18

Product Specifications

Product Name

Titanium bar / titanium rod

Standards

ASTM B348, ASTM F67, ASTM F136, AMS 4928

Materials

GR1, GR2, GR3, GR4, GR5

Diameter

0.8~500mm

Length

500~6000mm or custom

Product Status

Cold rolled (Y), Hot rolled (R), Annealed (M), Solid Status

Shapes

Round bar, square bar, hex bar

Certifications

ISO9001:2015, TUV, material test certificate acc EN10204.3.1

Key Features

Polished surface free from defects, cracks, and pittings
Two ends flatted for precise length tolerance and enhanced appearance
Excellent corrosion resistance and lightweight properties
Superior strength and durability for demanding applications
Easy machining and welding capabilities for customization
