200-1300mm Outer Diameter GR5 Titanium Alloy Forged Rings with Height 35-250mm

Brand Name:	LIHUA
Model Number:	LH-TH
MOQ:	1 pieces
Price:	US dollar $15/kg--US dollar $35/kg
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	5000 kgs per month

Detail Information

Product Description

Detail Information

Place of Origin:

Baoji, China

Certification:

ISO9001, TUV etc.

Product Name:

Titanium Forged Ring

Material:

Gr5

Application:

Chemical Industry

Outer Diameter:

200-1300mm

Inner Diameter:

100-900mm

Height:

35-250mm

Thickness:

40-400mm

Quality Control:

Ultrasonic Testing

Packaging Details:

Plywood box for export

Supply Ability:

5000 kgs per month

Highlight:

GR5 Titanium Alloy Forged Rings

200-1300mm Titanium Alloy Forged Rings

250mm Titanium Alloy Forged Rings

Product Description

GR5 Titanium Alloy Forged Rings

Basic Information
1, Brand:TA1, TA2, TA9, TA10, TC4, GR1, GR2, GR5, GR7, GR12.
2, Implementation standards:GB/T 16598, ASME SB381
3, Surface:Forged surface, Rolled surface, Smooth surface, Polished surface.
4, Application field:Used in aerospace, medical, chemical, petrochemical, Marine, electrolysis, electroplating and other industries.

Chemical requirements
	N	C	H	Fe	O	Al	V	Pd	Mo	Ni	Ti
Gr1	0.03	0.08	0.015	0.20	0.18	/	/	/	/	/	bal
Gr2	0.03	0.08	0.015	0.30	0.25	/	/	/	/	/	bal
Gr5	0.05	0.08	0.015	0.40	0.20	5.5~6.75	3.5~4.5	/	/	/	bal
Gr7	0.03	0.08	0.015	0.30	0.25	/	/	0.12~0.25	/	/	bal
Gr12	0.03	0.08	0.015	0.30	0.25	/	/	/	0.2~0.4	0.6~0.9	bal
