Product Details
Place of Origin: China
Brand Name: LHTi
Certification: ISO9001:2015; TUV; SGS;BV
Model Number: Titanium wire
Payment & Shipping Terms
Minimum Order Quantity: 20 kg
Price: USD16.00-28.00 per kg
Packaging Details: Plastic bag with laber, outside plastic box, then plywod box
Delivery Time: 7-20 work days
Payment Terms: T/T, MoneyGram, L/C, Western Union, Paypal
Supply Ability: 200000 kg per month
Material: |
Factory Direct-Sales Gr1 Gr2 Pure Titanium Wire For Welding AWS A5.16 Titanium Spool Wire |
Grade: |
Gr1, Gr2 |
Diameter: |
0.5mm-3mm |
Straight Wire Length: |
1000mm-3000mm |
MOQ: |
20 Kg |
Package Box: |
5kg Per Plastic Box, Or As Your Request |
Certificate: |
ISO9001:2008 |
Processing Service: |
Bending, Cutting |
Package Coil: |
10~15kg ,or As Per Buyer Requirement |
Advantage: |
Corrosion Resistance, High Strength, Light Quality |
Material: |
Factory Direct-Sales Gr1 Gr2 Pure Titanium Wire For Welding AWS A5.16 Titanium Spool Wire |
Grade: |
Gr1, Gr2 |
Diameter: |
0.5mm-3mm |
Straight Wire Length: |
1000mm-3000mm |
MOQ: |
20 Kg |
Package Box: |
5kg Per Plastic Box, Or As Your Request |
Certificate: |
ISO9001:2008 |
Processing Service: |
Bending, Cutting |
Package Coil: |
10~15kg ,or As Per Buyer Requirement |
Advantage: |
Corrosion Resistance, High Strength, Light Quality |
ERTi-2 titanium welding wire is usually used for welding industrial pure titanium. Because of its good strength and welding performance, it is widely used in the industry. Typical applications are welding of industrial pure titanium heat exchangers, seawater heat exchangers, pressure vessels, and piping systems in chemical engineering.
Titanium welding wire is a disk or single wire product obtained by drawing titanium and titanium alloy wire blanks (a disk or a single root).
| ASTM Base Metal Grade | Base metal | Normal composition | Recommended Filler Metal | |
| UTS(min.) ksi[Mpa] | YS(min.) ksi[Mpa] | |||
| Grade 1 | 35[240] | 20[138] | Unalloyed Ti CP1 | ERTi-1 |
| Grade 2 | 50[345] | 40[275] | Unalloyed Ti CP2 | ERTi-2 |
| Grade 4 | 80[550] | 70[483] | Unalloyed Ti CP4 | ERTi-4 |
| Grade 5 | 130[895] | 120[828] | Ti 6AL-4V | ERTi-5 |
| Grade 7 | 50[345] | 40[275] | Ti 0.15Pd | ERTi-7 |
| AWS | CHEMICAL SPECIFICATIONS | ||||||||
| AWS A5.16 | UNS | C | O | N | H | I | Al | V | Pd |
| Number | |||||||||
| ERTi 1 | R50100 | 0.03 | 0.03-0.10 | 0.012 | 0.005 | 0.08 | - | - | - |
| ERTi 2 | R50120 | 0.03 | 0.08-0.16 | 0.015 | 0.008 | 0.12 | - | - | - |
| ERTi 4 | R50130 | 0.03 | 0.08-0.32 | 0.025 | 0.008 | 0.25 | - | - | - |
| ERTi 5 | R56400 | 0.05 | 0.12-0.20 | 0.03 | 0.015 | 0.22 | 5.5-6.7 | 3.5-4.5 | - |
| ERTi 7 | R52401 | 0.03 | 0.08-0.16 | 0.015 | 0.008 | 0.12 | - | - | 0.12-0.25 |
| ASTM Base Metal Grade | Base metal | Normal composition | Recommended Filler Metal | |
| UTS(min.) ksi[Mpa] | YS(min.) ksi[Mpa] | |||
| Grade 1 | 35[240] | 20[138] | Unalloyed Ti CP1 | ERTi-1 |
| Grade 2 | 50[345] | 40[275] | Unalloyed Ti CP2 | ERTi-2 |
| Grade 4 | 80[550] | 70[483] | Unalloyed Ti CP4 | ERTi-4 |
| Grade 5 | 130[895] | 120[828] | Ti 6AL-4V | ERTi-5 |
| Grade 7 | 50[345] | 40[275] | Ti 0.15Pd | ERTi-7 |
