Product Details
Place of Origin: China
Brand Name: LHTI
Certification: ISO9001:2015; TUV; SGS;BV
Model Number: LH-12
Payment & Shipping Terms
Minimum Order Quantity: 10 kg
Price: USD13.00-52.00 per kg
Packaging Details: Coil and spool package in carton case or plywood case,straight wire package in Plastic case,outside is standard export plywood case
Delivery Time: In stock--3 days.production--15-20 working days
Payment Terms: L/C, D/P, T/T, Western Union,paypal etc
Supply Ability: 50000 kgs per month
Product Name: |
Titanium Welding Wire ErTi-5 1mm 1.6mm 2mm For MIG TIG AWS A5.16 |
Grade: |
Grade1 Grade2 ErTi1 ErTi2 |
Shape: |
Coil,spool,straight |
Material: |
Pure Titanium |
Surface: |
Pickling Surface/polish Surface |
Package: |
Standard Export Package |
Hot Sale Diameter: |
0.8mm-5mm Etc |
Length: |
1000mm |
Key Words: |
Thin Titanium Wire |
Product Name: |
Titanium Welding Wire ErTi-5 1mm 1.6mm 2mm For MIG TIG AWS A5.16 |
Grade: |
Grade1 Grade2 ErTi1 ErTi2 |
Shape: |
Coil,spool,straight |
Material: |
Pure Titanium |
Surface: |
Pickling Surface/polish Surface |
Package: |
Standard Export Package |
Hot Sale Diameter: |
0.8mm-5mm Etc |
Length: |
1000mm |
Key Words: |
Thin Titanium Wire |
2mm Titanium Alloy Wire
1. Products information
Grade : TA1,TA2,TC4,Gr7,Gr12,Gr23 ,ErTi-1,ErTi-2,ErTi-5,ErTi-7 etc
Standard : ASTM B863 (for industrial) / AWS a5.16(for welding)
Diameter : 0.8-6.0mm
Shape : coil,spool,straight.
Surface : pickling surface/bright surface
Application : industrial,welding,macine parts,medical etc
Welding wire analysis%:
C <0.08
Fe <0.25
O <0.18
H <0.013
N <0.05
Ti: balance
Gr1/Gr2/ErTi-1/ErTi-2 dia=0.8mm/1.0mm/1.2mm/1.6mm/2.0mm/2.4mm/2.5mm/3.0mm/3.5mm in stock,ensure delivery 3-5 days
Gr5/ErTI-5/Gr7/ErTI-7 some size in stock,some size need production,lead time 10 working days.according your quantity
Gr12/ErTi-12 need production,lead time 10 working days
| Common Ti Wires Tolerance | |||
| Diameter | 0.1-0.3mm | 0.3-0.8mm | 0.8-2.0mm |
| Tolerance | +/- 0.025 | +/-0.04 | +/-0.05 |
| Length | 200-500mm | 500-1000mm | 1000-2000mm |
| Tolerance | +/-1.0 | +/-1.5 | +/-2. |
| Grade | Tensile Strength (min) | Yield strength 0.2%Offset | Elongation in 2in. or 50mm % (min) | ||
| Min | |||||
| Ksi | Mpa | Ksi | Mpa | ||
| Gr1 | 35 | 240 | 20 | 138 | 20 |
| Gr2 | 50 | 345 | 40 | 275 | 18 |
| Gr3 | 65 | 450 | 55 | 380 | 18 |
| Gr5 | 130 | 895 | 120 | 828 | 10 |
| Gr7 | 50 | 345 | 40 | 275 | 18 |
| Gr12 | 70 | 483 | 50 | 345 | 18 |
2. Titanium wire---Three kinds of type for your choose
Titanium wire in Spool--dia<6.0mm ,if you need we can make spool wire
dia1.0-2.0mm,Precision winding,used for MIG
dia0.2mm-3.0mm,thin wire,used for titanium mesh
Spool OD=270mm to 300mm,one spool wire weight is about 6-10kgs.or as per requirment
Titanium wire in coil--dia>2.0mm,we can make Coil wire
Coil OD = 450mm,one coil weight is about 10-15kg,or as per requirment
Titanium wire in straight--dia=0.8mm/1.0mm/1.6mm/2.0mm/2.4mm/3.2mm,length=914mm to 1000mm
90% titanium straight wire used for welding(TIG filler rod)
