Product Details
Place of Origin: Baoji, China
Brand Name: LIHUA
Certification: ISO9001, TUV etc.
Model Number: titanium rod
Payment & Shipping Terms
Minimum Order Quantity: 100kg
Price: US dollar $25/kg--US dollar $40/kg
Packaging Details: Plywood box for export
Delivery Time: 5-15 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 3000 kgs per month
Product Name: |
8mm 10mm AMS 4928 AMS 6931 Aerospace Titanium Gr5 Ti6AL4V Titanium Rod |
Standard: |
AMS 4928 AMS6931 |
Application: |
Aerospace |
Shape: |
Round |
Length: |
As Per Your Requirements |
Surface: |
Bright |
Product Name: |
8mm 10mm AMS 4928 AMS 6931 Aerospace Titanium Gr5 Ti6AL4V Titanium Rod |
Standard: |
AMS 4928 AMS6931 |
Application: |
Aerospace |
Shape: |
Round |
Length: |
As Per Your Requirements |
Surface: |
Bright |
8mm 10mm AMS 4928 AMS 6931 Aerospace titanium gr5 Ti6AL4V titanium rod
Material: GR5 Ti-6Al-4V
Specification: titanium rod φ8mm ~ φ30mm × L (rolling) titanium rod φ30mm ~ φ400mm × L (forging)
Supply status: Annealing (M)
Executive standard: AMS 4928
QC:
(1) Strictly implement the requirements of ISO9001: 2008, the raw material titanium ingot and finished product are 100% ultrasonic flaw detection, and issue a flaw detection report
(2) Entrust third-party authoritative institutions to perform physical performance, mechanical performance and high-magnification metallographic testing, and issue testing reports.
Advantages:
(1) The company adopts domestic advanced smelting equipment-3 tons double chamber vacuum consumable arc furnace for multiple smelting, the entire smelting process is fully automated, the control accuracy is high, the smelting period is short, and the chemical composition of the titanium ingot produced is uniform , No inclusion, no segregation, small shrinkage cavity, high yield of titanium ingot. According to the requirements of aerospace titanium, multiple smelting processes are used to make the chemical composition of the product more uniform, the grain size is finer and the distribution is even, which ensures the physical properties of the product.
(2) The company adopts advanced forging equipment --- 2000 tons of free forging hydraulic press for blank forging, which can be set at a fixed pressure, and the hydraulic machine of the operating machine is controlled on the same table. The titanium and titanium alloy products have a uniform internal structure and stable and reliable performance.
(3) According to the requirements of aerospace titanium, multiple piercing processes are used in the forging process, which can effectively ensure the product structure and improve the mechanical properties of the product.
(4) Both natural gas furnaces and electric furnaces for forging adopt PLC automatic control system. Set the program to automatically heat up, keep warm, and automatically record heating data. Melting and forging and various heating data can be traced.
Main production equipment: 3500T electrode press, 3 tons double chamber vacuum consumable arc furnace, 2000T and 3500T free forging hydraulic press, 750 kg air hammer, natural gas heating furnace, resistance heating furnace, lathe, sawing machine, etc
Packaging: According to customer requirements or negotiation (export standard wooden box packaging).
Application areas: Titanium and titanium alloy products are widely used in chemical, machinery, petrochemical, aerospace, medical and other fields.
Physical Properties
Physical Properties | |||||
Tensile Strength(min) | Yield Strength(min) | Elongation(%) | |||
ksi | MPa | ksi | MPa | ||
Grade 1 | 35 | 240 | 20 | 138 | 24 |
Grade2 | 50 | 345 | 40 | 275 | 20 |
Grade 3 | 65 | 450 | 55 | 380 | 18 |
Grade 4 | 80 | 550 | 70 | 483 | 15 |
Grade 5 | 130 | 895 | 120 | 828 | 10 |
Grade 7 | 50 | 345 | 40 | 275 | 20 |
Grade 9 | 90 | 620 | 70 | 483 | 15 |
Grade 12 | 70 | 483 | 50 | 345 | 18 |
Grade 23 | 120 | 828 | 110 | 759 | 10 |
Chemical Composition
Titanium Bar | |||||||||
Grade | Ti | Al | V | Nb | Fe, max | C, max | N, max | H, max | O, max |
Gr1 | Bal | / | / | 0.20 | 0.08 | 0.03 | 0.015 | 0.18 | |
Gr2 | Bal | / | / | 0.30 | 0.08 | 0.03 | 0.015 | 0.25 | |
Gr3 | Bal | / | / | 0.30 | 0.08 | 0.05 | 0.015 | 0.35 | |
Gr4 | Bal | / | / | 0.50 | 0.08 | 0.05 | 0.015 | 0.40 | |
Gr5 ELI Ti-6Al-4VELI |
Bal | 5.5~6.5 | 3.5~4.5 | 0.25 | 0.08 | 0.05 | 0.012 | 0.13 | |
Ti-6Al-7Nb | Bal | 5.5-6.5 | / | 6.5-7.5 | 0.25 | 0.08 | 0.08 | 0.009 | 0.20 |
Titanium Round Bar | |||
Diameter (Inches) | Appx. Weight Per Foot | Diameter (Inches) | Appx. Weight Per Foot |
0.1875 | .05 | 3.25 | 16.22 |
0.25 | .10 | 3.5 | 18.82 |
0.3125 | .15 | 3.75 | 21.60 |
0.375 | .22 | 4.0 | 24.58 |
0.4375 | .29 | 4.25 | 27.74 |
0.5 | .38 | 4.5 | 31.10 |
0.5625 | .48 | 4.75 | 34.01 |
0.625 | .60 | 5.0 | 37.68 |
0.6875 | .71 | 5.25 | 41.54 |
0.75 | .86 | 5.5 | 46.46 |
0.8125 | .99 | 5.75 | 49.83 |
0.875 | 1.18 | 6.0 | 55.30 |
0.9375 | 1.32 | 6.25 | 58.88 |
1.0 | 1.54 | 6.5 | 64.80 |
1.125 | 1.94 | 7.0 | 75.30 |
1.25 | 2.40 | 7.5 | 86.40 |
1.375 | 2.90 | 8.0 | 98.30 |
1.5 | 3.46 | 8.25 | 104.60 |
1.625 | 3.98 | 8.5 | 111.00 |
1.750 | 4.62 | 9.0 | 124.40 |
1.875 | 5.40 | 9.5 | 138.60 |
2.0 | 6.14 | 10.0 | 153.60 |
2.25 | 7.78 | 11.0 | 185.90 |
2.375 | 8.50 | 12.0 | 212.20 |
2.5 | 9.60 | 13.0 | 259.60 |
2.625 | 10.58 | 14.0 | 301.10 |
2.75 | 11.62 | 15.0 | 351.40 |
3.0 | 13.82 | 16.0 | 385.90 |
Tolerance
Diameter(mm) | h7 | h8 | h9 | h10 | h11 | h12 | |
Tolerance precision (um) | |||||||
3~6 | 12 | 18 | 30 | 48 | 75 | 120 | |
6~10 | 15 | 22 | 36 | 58 | 90 | 150 | |
10~18 | 18 | 27 | 43 | 70 | 110 | 180 | |
"h"stands for a tolerance range(-x,+0),on the contrary,"H"stands for a tolerance(-0,+X) |
