10mm Titanium Tube with Superior Corrosion Resistance – Ideal for Diverse Applications / grade 5 titanium tube

Brand Name:	LHTI
Model Number:	LH-01
MOQ:	If in stock, sample is available; If not in stock,100kgs of each size
Price:	US dollar $23.5/kg--US dollar $35.9./kg
Supply Ability:	5 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001

Packing:

Standard Exported Wooden Cases

Meltingpoint:

1660℃

Wall Thickness:

Customizable

Corrosion Resistance:

High

Surface Treatment:

Polished

Type:

Seamless

Situation:

Annealed

Hs Code:

8108904090

Original:

China

Outer Diameter:

9.52/12.7/15.9/19.1/25.4/32/33.4/38.1mm

Heat Capacity:

3kw~500kw Or More

Specific Use:

Heating And Cooling

Diameter:

Customizable

Application:

Aerospace, Chemical Processing, Medical, Marine, Oil And Gas

Weldability:

Good

Packaging Details:

Each tube with environmental protection bags,outside is standard plywood case

Supply Ability:

5 tons per month

Product Description

10mm Titanium Tube with Superior Corrosion Resistance – Ideal for Diverse Applications / grade 5 titanium tube

Product Features

High Strength
Titanium tubes exhibit impressive strength, with tensile strength ranging from 686 to 1176 MPa. Despite having a density about 60% that of steel, they offer a remarkably high specific strength.
High Hardness
Titanium alloy seamless tubes possess notable hardness, with an HRC rating of 32-38 in the annealed state.
Low Elastic Modulus
The elastic modulus of annealed titanium alloy seamless tubes ranges from 1.078 × 10^4 to 1.176 × 10^4 MPa, approximately half that of steel and stainless steel.

Standards: ASTM B338, ASTM B861

Tensile requirements
Grade	Tensile srength(min)		Yeild strength(mm)		Elongation(%)
	KSI	MPa	Ksi	MPa
1	35	240	20	138	24
2	50	345	40	275	20
5	130	895	120	828	10
7	50	345	40	275	20
12	70	438	50	345	18

Chemical requirements
	N	C	H	Fe	O	Al	V	Pd	Mo	Ni	Ti
Gr1	0.03	0.08	0.015	0.20	0.18	/	/	/	/	/	bal
Gr2	0.03	0.08	0.015	0.30	0.25	/	/	/	/	/	bal
Gr5	0.05	0.08	0.015	0.40	0.20	5.5~6.75	3.5~4.5	/	/	/	bal
Gr7	0.03	0.08	0.015	0.30	0.25	/	/	0.12~0.25	/	/	bal
Gr12	0.03	0.08	0.015	0.30	0.25	/	/	/	0.2~0.4	0.6~0.9	bal

10mm Titanium Tube with Superior Corrosion Resistance – Ideal for Diverse Applications / grade 5 titanium tube 0

Ideal for Diverse Applications / grade 5 titanium tube.
