TiAl Titanium Sputtering Target Disc Gr1-Gr12

Brand Name:	LHTi
Model Number:	LH-Disc
MOQ:	5 pcs
Price:	US dollar $20/pc--US dollar $30/pc
Payment Terms:	L/C,D/P,T/T,Western Union，paypal
Supply Ability:	5000 pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

Baoji, China

Certification:

ISO9001, TUV etc.

Ti Content (%)::

99.7% Min

Product Name::

Titanium Disc

Material::

Gr1 Gr2 Gr5 Gr7 Gr9 Gr12

Color::

Silver Gray

Technology::

Cold Colled Stamping

Density::

4.51g/cm^3

Packed::

Wooden Case

Purity::

>99.7%

Packaging Details:

Plastic bag with laber, outside plastic box, then plywod box

Supply Ability:

5000 pcs per week

Highlight:

titanium alloy sputtering targets

titanium coating targets

tial alloy sputtering targets

Product Description

TiAl Titanium Sputtering Target Disc Gr1-Gr12

Titanium and titanium alloy targets are used for coating in vacuum deposition processes. Made from titanium cake with low density and high strength, they offer low temperature resistance and high temperature corrosion resistance, and are widely used in vacuum salt making, fine chemical industry, petrochemical, chlor-alkali industry, electroplating, electrolysis, aerospace and seawater desalination. This TiAl titanium disc is supplied in Gr1 through Gr12 with a titanium content of 99.7% minimum.

TiAl Titanium Sputtering Target Disc

Technical Specifications

Product Name	Titanium disc / TiAl alloy target
Material	Gr1, Gr2, Gr5, Gr7, Gr9, Gr12
Ti Content	99.7% min (purity >99.7%)
Density	4.51 g/cm³
Technology	Cold rolled stamping
Colour	Silver grey
Packed	Wooden case

Chemical Requirements (max %)

Grade	N	C	H	Fe	O	Al	V	Pd	Mo	Ni	Ti
Gr1	0.03	0.08	0.015	0.20	0.18	/	/	/	/	/	bal
Gr2	0.03	0.08	0.015	0.30	0.25	/	/	/	/	/	bal
Gr5	0.05	0.08	0.015	0.40	0.20	5.5-6.75	3.5-4.5	/	/	/	bal
Gr7	0.03	0.08	0.015	0.30	0.25	/	/	0.12-0.25	/	/	bal
Gr12	0.03	0.08	0.015	0.30	0.25	/	/	/	0.2-0.4	0.6-0.9	bal

Tensile Requirements

Grade	Tensile Strength min (KSI / MPa)	Yield Strength min (KSI / MPa)	Elongation (%)
1	35 / 240	20 / 138	24
2	50 / 345	40 / 275	20
5	130 / 895	120 / 828	10
7	50 / 345	40 / 275	20
12	70 / 438	50 / 345	18

Applications & Titanium Advantages

These targets and titanium cakes are used in vacuum salt making, fine chemicals, petrochemical, electroplating, electrolysis, aerospace, seawater desalination and similar industries, including forged titanium cakes for the top and bottom covers of petrochemical equipment. Titanium offers low density, high strength, low temperature resistance and excellent high temperature corrosion resistance, keeping coating and process equipment reliable over long service.

Quality, Customization & Inquiry

Baoji Lihua (LHTi) has produced nonferrous metals since 2006 under ISO 9001:2015 and BV audit certification, with CNC, milling and drilling equipment and strict quality control. Dimensions and grades can be customized and discounts are offered according to order quantity. Please send your specification for a quotation.
