Gr7 Titanium Tubing 12.7mm ASTM B338 Pickled

Brand Name:	LHTI
Model Number:	LH-01
MOQ:	If in stock, sample is available; If not in stock,100kgs of each size
Payment Terms:	L/C,D/P,T/T,Western Union,Paypal.etc
Supply Ability:	5 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

BaoJi Shaanxi China

Certification:

ISO9001

Standard:

ASTM B338

Grade:

Gr1 Gr2 Gr7 Gr12

OD:

12.7mm 15.2mm 17.8mm 19mm 25.4mm 38.1mm

Wall Thickness:

1.0mm/1.2mm Or As Customized

Material:

Pure Titanium

Purity:

99.5%min

Length:

Max 16 Meter

Surface:

Pickling Surface

Application:

Heat Exchanger

Production Time:

15 Working Days

Payment Term:

T/T,Paypal,Western Union Etc

Key Words:

Titanium Seamless Tube

Packaging Details:

Each tube with environmental protection bags,outside is standard plywood case

Supply Ability:

5 tons per month

Highlight:

Gr7 Welding Titanium Tubing

OD 12.7mm Welding Titanium Tubing

99.5% Purity Welding Titanium Tubing

Product Description

Gr7 Titanium Tubing 12.7mm ASTM B338 Pickled

Gr7 titanium tubing with a 12.7mm outside diameter is manufactured to ASTM B338 in Grade 1, Grade 2, Grade 7 and Grade 12. Titanium tubes are commonly used in heat exchangers, condensers, transportation pipelines and oil and gas equipment, and are supplied in both seamless and welded types. Under strict quality control, every tube undergoes 100% flaw detection or X-ray inspection together with a physical and chemical inspection report.

Gr7 Titanium Tubing

Technical Specifications

Standard	ASTM B338, ASTM B337, ASTM B861, AMS B862
Grade	Gr1, Gr2, Gr7, Gr12
Outside Diameter	12.7mm, 15.2mm, 17.8mm, 19mm, 25.4mm, 38.1mm
Wall Thickness	1.0mm, 1.2mm or customized
Material	Pure titanium
Purity	99.5% min
Length	Max 16 meter
Surface	Pickling surface
Application	Heat exchanger

Available Sizes

Type	Size Range
Rolled titanium seamless pipe	φ13~159 × 0.2~10 × L
Extruded seamless pipe	φ2.35~219 × 0.2~10 × L
Welded titanium pipe	φ30~500 × 0.5~8.0 × L

Mechanical Properties by Grade

Grade	Fe max (%)	O max (%)	Elongation (%)	Tensile Strength (MPa)	Yield Strength (MPa)
Gr1	0.2	0.18	24	240	140
Gr2	0.3	0.25	20	400	275
Gr7	0.3	0.25	20	400	275
Gr12	0.3	0.25	18	460	300

Applications & Titanium Advantages

This titanium tubing is used in heat exchangers, condensers, transportation pipelines, the oil and gas industry and sporting goods. Titanium is light, strong and highly corrosion resistant, so tubes resist aggressive media and keep heat-transfer performance over long service. LHTi is certified to ISO 9001 and supplies titanium tubes to leading oil and gas manufacturers for heat exchangers, air coolers and other process equipment.

Quality, Customization & Inquiry

LHTi carries out dimension inspection, tensile testing, UT, PT, chemical composition inspection, hydrostatic test, eddy current inspection, radiographic inspection, thickness inspection and PMI inspection, and issues material certificates. Various titanium tube specifications can be customized to customer requirements, and sample material is available if in stock. Please send your specification for a quotation.
