| Place of Origin: | Baoji City Shaanxi Province China |
|---|---|
| Brand Name: | LHTi |
| Certification: | ISO9001 |
| Model Number: | LHTI-042 |
| Minimum Order Quantity: | 100kg |
| Price: | USD5-38 per kg |
| Packaging Details: | Standard foreigh packing, plastic inside and plywood case outside Or as the clients' request |
| Delivery Time: | 7-30work days |
| Payment Terms: | T/T, Western Union, L/C |
| Supply Ability: | 5Ton per month |
| Standard: | AWS 5.16 | Color: | Ti Natural |
|---|---|---|---|
| Surface: | Polished | Type: | Straight / Spool / Coil |
| Certificate: | ISO9001:2015 | Technique: | Cold Rolling |
| Purity: | 99.95% | Advantage: | Hot Resistance |
| High Light: | thin titanium wire,pure titanium wire |
||
Gr7 Titanium Wire for Plating Hangers High-Quality Titanium wire own factory
1. Product description
1. Precision Gr1, Gr2 Gr5, Gr7, Gr9, Gr12 Titanium Wire in Titanium with Bright Surface
2. Titanium wire Material Grade:
TA1,TA2,TA3,TA4,TA7,TA9,TA10,TA15,TA18,TA19,TC3,TC4,TC6,TC11,TC17,TC18,TC19,TC20,
TC25,TB2,TB6,7715D,STi80,GR1,GR2,GR3,GR4,GR6,GR12,GR9,Ti-6242S,GRF-5,GR23,Ti-6246,Ti-10-2-3,BT1-00,BT1-0,BT5-1,BT20,BT6C,BT6,BT3-1,BT9,BT22 and so on.3.Standard: ASTM BS JIS NF DIN GB
3. Titanium wire Size:0.05mm-10mm
4. The length of the titanium wire is 500mm/1000mm/2000mm or coils.
5. The process of the titanium wire: hot rolled, cold drawn
6. The surface of the titanium wire: mill surface, polished surface
Gr5 titanium alloy stamping poor, good thermoplastic. It can be carried out in various forms of welding, welding joint strength up to 90% of the base metal strength. Mechanical processing performance is still good, it needs to use carbide cutting tools, large walking volume, slow, full cooling. Good corrosion resistance, good thermal stability. Gr5 Titanium is one of the most widely used titanium alloys. Do more than 400 Temper long-term work of the parts.
2. Titanium wire parameter information
| Item name | Titanium wire |
| Standard | ASTM B863,ASTMF136,ASTMF1295,ASTMF67,AWSA5.16,ISO5832-2,ISO5832-3 |
| Material | Gr1,Gr2,Gr3,Gr4,Gr5,Gr7,Gr9,Gr11,Gr12,gr23,ERTi-1,ERTi-2,ERTi-3,ERTi-4,ERTi-5ELi,ERTi-7,ERTi-9,ERTi-11,ERTi-12,ERTi-23,Ti-15333 |
| Diameter | 0.1~7.0mm |
| Length | in spool,in coil, in straight 915~1000mm or per customer request |
| Product Status | Cold-rolled(Y)~Hot rolled(R)~Annealed (M)~Solid Status |
| technology | annealed |
|
Titanium & Titanium Alloy Wire |
Grade |
Tensile strength |
Yield strength 0.2% offset yield |
Elongation in 2 or 50mm Min % |
| Min Mpa | Min Mpa | |||
| 1 | 240 | 170 | 20 | |
| 2 | 345 | 275 | 18 | |
| 2H | 345 | 275 | 18 | |
| 3 | 450 | 380 | 18 | |
| 5 | 895 | 828 | 10 | |
| 7 | 345 | 275 | 18 | |
| 7H | 400 | 275 | 18 | |
| 9 | 620 | 483 | 15 | |
| 12 | 483 | 345 | 18 |
3. Detailed Images
3. Company Information
| Product | titanium welding wire |
| Item Name | Hot sale ERTi-1 ERTi-2 ERTi-5 ERTi-7 ERTi-12 titanium welding rod |
| Standard | AWS A5.16 |
| Application | welding |
| Material | Gr2 pure titanium |
| Dia | 0.8mm 1.0mm 1.2mm 1.6mm 2.0mm 2.4mm 3.0mm 3.2mm |
| Length | As per your requirements |
| Shape | Straight |
| Certificate | ISO 9001, TUV, EN10204.3.1 certificate |
4. Applications for industrial
1.Nuclear power,
2.Environmental protection,
3.Aerospace,
4.Chemical enterprises,
5.Oil drilling,
6.Desulfurization and denitrification,
7.Nuclear submarine,
8.Surgical,
9.others
Titanium alloy wire with high strength and small density, good mechanical properties, toughness, and corrosion resistance is very good. In addition, the titanium alloy process performance is poor, cutting difficult, in the hot work, it is very easy to absorb impurities such as nitrogen and nitrogen. There is poor wear resistance, the production process is complex.
Titanium alloy wire is mainly used for the production of aircraft engine compressor parts, followed by rockets, missiles, and high-speed aircraft structural parts. titanium and titanium alloy wire used in the general industry for the manufacture of electrodes in the electrolysis industry, condensers for power stations, heaters for oil refining and desalination, and environmental pollution control devices. Titanium wire and titanium alloy have become a corrosion-resistant structural material. Also used in the production of hydrogen storage materials and shape memory alloys.
