Cold Rolling Thin Titanium Wire Polished Surface Gr12 Gr7 Hot Resistance

Brand Name:	LHTi
Model Number:	LHTI-040
MOQ:	100kg
Price:	USD11-38 per kg
Payment Terms:	T/T,Western Union,L/C
Supply Ability:	5Ton per month

Detail Information

Product Description

Detail Information

Place of Origin:

Baoji City Shaanxi Province China

Certification:

ISO9001

Standard:

AWS A5.16

Color:

Ti Natural

Surface:

Polished

Type:

Straight / Spool / Coil

Certificate:

ISO9001:2015

Technique:

Cold Rolling

Purity:

99.5%

Advantage:

Hot Resistance

Packaging Details:

Standard foreigh packing, plastic inside and plywood case outside Or as the clients' request

Supply Ability:

5Ton per month

Highlight:

titanium alloy wire

thin titanium wire

Product Description

Cold Rolling Thin Titanium Wire with Polished Surface

High-performance titanium wire available in Gr12 and Gr7 grades with excellent hot resistance properties, manufactured through cold rolling and polishing processes.

Product Specifications

Item Name	Titanium Wire
Standard	ASTM B863, ASTMF136, ASTMF1295, ASTMF67, AWSA5.16, ISO5832-2, ISO5832-3
Material Grades	Gr1, Gr2, Gr3, Gr4, Gr5, Gr7, Gr9, Gr11, Gr12, Gr23, ERTi-1, ERTi-2, ERTi-3, ERTi-4, ERTi-5ELi, ERTi-7, ERTi-9, ERTi-11, ERTi-12, ERTi-23, Ti-15333
Diameter Range	0.1~7.0mm
Length Options	In spool, in coil, in straight 915~1000mm or per customer request
Product Status	Cold-rolled (Y), Hot rolled (R), Annealed (M), Solid Status
Technology	Annealed

Titanium & Titanium Alloy Wire Mechanical Properties

Grade	Tensile Strength Min (MPa)	Yield Strength 0.2% Offset Min (MPa)	Elongation in 2 or 50mm Min (%)
1	240	170	20
2	345	275	18
2H	345	275	18
3	450	380	18
5	895	828	10
7	345	275	18
7H	400	275	18
9	620	483	15
12	483	345	18

Product Images

Manufacturer Information

BAOJI LIHUA NON-FERROUS METALS CO., LTD is located in Baoji, the titanium valley of China. As a leading manufacturer of titanium products for over 15 years, we supply a series of high-performance products including titanium flange, titanium bar, and titanium wire.

The industrial production of titanium began in 1948. The need for the development of the aviation industry has enabled the titanium industry to grow at an average annual growth rate of about 8%. Currently, the annual output of titanium alloy processed materials worldwide has reached more than 40,000 tons, with nearly 30 different titanium alloy grades available.

The most widely used titanium alloys are Ti-6Al-4V (TC4), Ti-5Al-2.5Sn (TA7), and industrial pure titanium (TA1, TA2, and TA3).

Titanium Welding Wire Specifications

Product	Titanium Welding Wire
Item Name	Hot sale ERTi-1 ERTi-2 ERTi-5 ERTi-7 ERTi-12 titanium welding rod
Standard	AWS A5.16
Application	Welding
Material	Gr2 Pure Titanium
Diameter Options	0.8mm, 1.0mm, 1.2mm, 1.6mm, 2.0mm, 2.4mm, 3.0mm, 3.2mm
Length	As per your requirements
Shape	Straight
Certification	ISO 9001, TUV, EN10204.3.1 certificate
