Gr1 Gr2 Two Way Ball Valve Titanium Ball Valve 2 Inch for Industrial Applications

Name: Gr1 Gr2 Two Way Ball Valve Titanium Ball Valve 2 Inch for Industrial Applications
Brand: Baoji Lihua Nonferrous Metals Co., Ltd.
SKU: TItanium Ball Valve
Price: 22,899.08 USD
Availability: InStock

Brand Name:	LHTi
Model Number:	TItanium Ball Valve
MOQ:	100 pieces
Price:	negotiable
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	200 Ton/Tons Per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Baoji, China

Certification:

ISO9001,CE,etc

Sealing Method:

Floating Ball, Trunnion Mounted

Product Type:

Ball Valve

Surface:

Metallic Luster

Cavity Filled:

Yes

Valve Type:

Ball Valve

Body Type:

2-Piece, 3-Piece

Ball Materials:

Titanium TA1、TA2、TA10、Gr2、Gr3

High Temperature Service:

Yes

Fire Safe Design:

API 607, API 6FA

Port Rating:

ASME Class 150, Flanged Ends

Packaging Details:

Plywood case or pallet, or as per your requirement

Supply Ability:

200 Ton/Tons Per Month

Highlight:

Industrial Applications Titanium Ball Valve

Gr1 Gr2 Titanium Ball Valve

2 Inch Titanium Ball Valve

Product Description

Gr1 & Gr2 Titanium Two-Way Ball Valve (2-Inch) for Industrial Applications

The Gr1 and Gr2 Titanium Two-Way Ball Valve (2-Inch) is a high-performance valve solution designed for industrial applications requiring superior corrosion resistance, strength, and reliability. Made from Grade 1 and Grade 2 titanium, these valves are ideal for handling aggressive and corrosive fluids in oil & gas, petrochemical, chemical processing, and marine environments. The two-way configuration provides optimal performance and flexible flow control in challenging conditions.

Key Features

Titanium Construction: Excellent corrosion resistance and high strength
Two-Way Operation: Bi-directional flow control for versatile applications
Compact Design: 2-inch size for space-constrained installations
Long-Lasting Durability: Exceptional fatigue strength and temperature resistance
Leak-Proof Sealing: High-performance design ensures minimal leakage

Material Comparisons: Gr1 vs Gr2 Titanium

Property	Gr1 Titanium	Gr2 Titanium
Tensile Strength	240 MPa (minimum)	480 MPa (minimum)
Yield Strength	170 MPa (minimum)	275 MPa (minimum)
Elongation	24% (minimum)	20% (minimum)
Density	4.51 g/cm³	4.43 g/cm³
Corrosion Resistance	Excellent (good for mild conditions)	Excellent (better suited for harsher environments)
Fatigue Strength	Good	Excellent

Technical Specifications

Specification	Details
Valve Type	Two-Way Ball Valve
Material Options	Gr1 or Gr2 Titanium
Size	2 Inch (DN 50)
Pressure Rating	ASME Class 150, 300
Temperature Range	-50°C to 450°C
Flow Control	Bi-directional Flow
End Connections	Flanged, Threaded, or Welded
Sealing Type	Leak-proof, high-performance design
Application	Oil & Gas, Petrochemical, Chemical Processing, Marine
Standard Compliance	ASME B16.34, API 6D

Applications

Oil & Gas Industry: Offshore platforms, pipelines, and refineries requiring high corrosion resistance
Petrochemical Processing: Handling aggressive chemicals, acids, and gases in chemical plants
Chemical Processing: Reliable flow control with corrosive and hazardous chemicals
Marine Environments: Shipbuilding, offshore rigs, and desalination plants with seawater exposure
