ASME B16.5 Class 150 Titanium Gr1 Gr2 Blind Flange with UT PT Testing for Chemical Applications

Name: ASME B16.5 Class 150 Titanium Gr1 Gr2 Blind Flange with UT PT Testing for Chemical Applications
Brand: Baoji Lihua Nonferrous Metals Co., Ltd.
SKU: Blind Flange
Price: 1,503.00 USD
Availability: InStock

Brand Name:	LHTi
Model Number:	Blind Flange
MOQ:	100 pieces
Price:	negotiable
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	500 Ton/Tons Per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Baoji, China

Certification:

ISO9001,CE,etc

Seal Face:

RF, FF, FM, M,RJ

Main Product:

Seamless & Welded Steel Pipe,flange

Flange Standards:

ASME B16.5

Press:

Class 600/ CL600

Application:

Chemical, Petrochemical, Oil & Gas, Power Generation, Aerospace, Marine

Pressure:

PN 10

Inspection:

UT%

Surface:

FF, RF, TG, RJ, Etc

Craft:

Casting

End Type:

Raised Face

Quality Test:

UT,PT Etc.

Ut Test Standard:

GB/T 5193

Unit Price:

$25usd/pc-$85usd/pc

Production Method:

Forged, Die Forged

Powder Or Not:

Not Powder

Packaging Details:

Plywood case or pallet, or as per your requirement

Supply Ability:

500 Ton/Tons Per Month

Highlight:

ASME B16.5 Raised Face BL Flanges

Chemical Titanium Gr1 Gr2 Flanges

ASME B16.5 Titanium Gr1 Gr2 Flanges

Product Description

ASME B16.5 Class 150 Titanium Gr1 & Gr2 Raised Face Blind Flanges

These titanium blind flanges provide exceptional corrosion resistance and high strength, making them ideal for demanding chemical applications where resistance to aggressive environments is critical. Manufactured to ASME B16.5 standards, they ensure precise dimensions and reliable performance.

Titanium Grade Comparison

Titanium Grade 1 (Ti Gr1):
- Composition: 99.5% titanium
- Properties: Soft, ductile, and highly corrosion-resistant
- Applications: Ideal for mild chemical environments where corrosion resistance is paramount
Titanium Grade 2 (Ti Gr2):
- Composition: 99.2% titanium with trace amounts of iron and oxygen
- Properties: Higher strength than Grade 1, better performance under mechanical stress and at elevated temperatures
- Applications: Designed for demanding chemical processes requiring higher mechanical strength

Technical Specifications

Flange Size (inches)	Outside Diameter (OD)	Bolt Circle Diameter (BCD)	Number of Bolt Holes	Bolt Hole Diameter	Thickness (T)	Pressure Rating (psi)
1/2"	3.5"	2.75"	4	0.5"	0.375"	150
1"	4.5"	3.75"	4	0.5"	0.375"	150
2"	6.5"	5.5"	4	0.5"	0.375"	150
4"	9.0"	7.5"	8	0.75"	0.5"	150
6"	12.0"	10.0"	8	0.75"	0.625"	150
8"	14.5"	12.0"	8	0.75"	0.75"	150

Note: Dimensions shown are approximate for ASME B16.5 Class 150 flanges. Exact measurements may vary by manufacturer.
