Sizes 1/2'' to 48'' Titanium Blind Flange with Polished Surface Treatment Durable

Name: Sizes 1/2'' to 48'' Titanium Blind Flange with Polished Surface Treatment Durable
Brand: Baoji Lihua Nonferrous Metals Co., Ltd.
SKU: LH-BL
Price: 55.00 USD
Availability: InStock

Product Details

Place of Origin: Baoji, China

Brand Name: LIHUA

Certification: ISO9001, TUV etc.

Model Number: LH-BL

Payment & Shipping Terms

Minimum Order Quantity: If in stock, sample is available; If not in stock,100kgs of each size

Price: US dollar $30/pc--US dollar $80/pc

Packaging Details: Wrapped by foam contained in plywood box for export

Delivery Time: 3-15 work days

Payment Terms: T/T, Western Union, D/A, L/C

Supply Ability: 5 tons per month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                48 Titanium Blind Flange, Durable Titanium Blind Flange, Polished Surface Treatment Titanium Blind Flange


Features:	High Strength, Good Corrosion Resistance	Surface:	CNC Machine Finished
Sizes:	1/2'' Inches To 48'' Inches	Material:	Titanium
Weight:	1kg~500kg	Standard:	ASME B16.5, ASME B16.47, MSS SP-44, API, DIN, JIS, GB
Pressure Rating:	Class 150 - Class 2500	Application:	Chemical, Petrochemical, Oil & Gas, Power Generation, Marine, Aerospace
Connection:	Welding	Working Temp:	-60℃~250℃
Type:	Type 11B WN Flange	Diameter:	Custom Made
Face:	Raised Face	Constitute:	A Pair Of Flanges, A Gasket
Processing Method:	Forged, CNC Machine

Features:	High Strength, Good Corrosion Resistance
Surface:	CNC Machine Finished
Sizes:	1/2'' Inches To 48'' Inches
Material:	Titanium
Weight:	1kg~500kg
Standard:	ASME B16.5, ASME B16.47, MSS SP-44, API, DIN, JIS, GB
Pressure Rating:	Class 150 - Class 2500
Application:	Chemical, Petrochemical, Oil & Gas, Power Generation, Marine, Aerospace
Connection:	Welding
Working Temp:	-60℃~250℃
Type:	Type 11B WN Flange
Diameter:	Custom Made
Face:	Raised Face
Constitute:	A Pair Of Flanges, A Gasket
Processing Method:	Forged, CNC Machine

Sizes 1/2'' to 48'' Titanium Blind Flange with Polished Surface Treatment Durable

ASME B16.47 Titanium Flange with Large Male-Female Connection for High Pressure Systems

Product Description:

This titanium blind flange, designed for DIN applications and rated for 1500 pressure, is extensively used in water conservancy, electric power, power stations, pipe fittings, and pressure vessels. Forged for high durability, it is ideal for both machinery and chemical applications. We also offer flanges in additional materials such as nickel and zirconium.

The Polishing Surfaced Titanium Blind Flange is a high-quality component designed for pipe connections in various applications. Crafted from premium titanium, it ensures a long service life and exceptional durability. The flange features a polished surface treatment, which enhances its corrosion resistance and overall appearance. It offers superior sealing performance and is compliant with certifications such as ISO, CE, and API. Available in various packaging options, including wooden cases and pallets, this blind flange is highly valued for its precision engineering and reliability. It is an excellent choice for diverse industrial pipe systems and applications.

Features:

Product Name: Polishing Surfaced Titanium Blind Flange
Certificates: ISO, CE, API, etc.
Standards: ANSI, JIS, DIN, etc.
Packaging: Wooden Case, Pallet, etc.
MOQ: 1 Piece
Connection Type: Welding
Options: Titanium SO Flange, Titanium Thread Flange, Titanium Plate Flange

Physical Properties

Grade	Tensile strength(min)		Yeild strength(min)		Elongation (%)
Grade	ksi	MPa	ksi	MPa	Elongation (%)
GR1	35	240	20	138	24
GR2	50	345	40	275	20
GR5	130	895	120	828	10
GR7	50	345	40	275	20
GR9	90	620	70	438	15
GR12	70	438	50	345	18

Product name	Titanium flange
Type	WN
Standards	ASME B16.5 ASTM B381
Size	1/2" to 36"
Pressure Ratings	Class 150, 300#, 600#, CL 900, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64
Grade	gr2 gr5 gr7 gr12
Other Flanges Types	Lapped Joint Flanges, Flat Flanges, Blind Flanges, Square Flanges, RTJ Flanges, Long Neck Weld Flanges, Reducing Flanges, Nipo Flanges, Threaded Flanges, Orifice Flanges, Expander Flanges, Socket Weld Flanges, High Hub Blinds Flanges, Forged Flanges, Slip On Flanges etc

Sizes 1/2'' to 48'' Titanium Blind Flange with Polished Surface Treatment Durable 0

About Us:

In the last 15 years in the titanium manufacturing and exporting industry, we have excelled in crafting a wide array of titanium flanges. Our offerings include blind, neck, lap, slip-on, and plate flanges, with sizes ranging from ½" to 24". Complying with ASTM B/SB 381 standards, our products are precise and reliable. Whether you require a high volume for a major project or a single flange for a smaller task, we have the capability to deliver promptly and meet all your project needs effectively.
