DN50 Titanium Flange ANSI B16.5 Ti-Pd Alloy Welding Neck Pipe Connector For Industrial

Name: DN50 Titanium Flange ANSI B16.5 Ti-Pd Alloy Welding Neck Pipe Connector For Industrial
Brand: Baoji Lihua Nonferrous Metals Co., Ltd.
SKU: LH-BL
Price: 55.00 USD
Availability: InStock

Brand Name:	LIHUA
Model Number:	LH-BL
MOQ:	100 kgs
Price:	US dollar $30/pc--US dollar $80/pc
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	5 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

Baoji, China

Certification:

ISO9001, TUV etc.

Specifications:

Complete

Standard:

ASME B16.5, ASME B16.47, MSS SP-44, API, DIN, JIS

Quality Test:

UT,PT Etc.

Process:

Welded

Craft:

Casting

Packaging Details:

Wrapped by foam contained in plywood box for export

Supply Ability:

5 tons per month

Highlight:

Industrial Titanium Flange

ANSI B16.5 Titanium Flange

DN50 Titanium Flange

Product Description

DN50 Titanium Welding Neck Flange - ANSI B16.5 Ti-Pd Alloy WN Pipe Connector / metal flange

Production Information

The DN50 Blind Flange is a high-quality metal flange designed to provide a secure and reliable closure for pipe systems. With a nominal diameter of 50 mm, this blind flange is crafted from durable materials to ensure long-lasting performance and resistance to various industrial conditions.

Key specifications include:

Material: Typically manufactured from stainless steel, carbon steel, or titanium, depending on the application's requirements.
Standards: Conforms to industry standards such as ANSI B16.5 or similar for compatibility and reliability.
Pressure Rating: Available in various pressure classes, such as PN6, PN10, PN16, and others, to accommodate different system pressures.
Sealing Surface: Comes with different sealing surfaces such as Raised Face (RF), Flat Face (FF), and Ring Joint (RJ) for optimal sealing performance.
Size Range: Although the specific size here is DN50, blind flanges are available in various sizes to meet diverse application needs.
Ideal for use in systems requiring a temporary or permanent seal, the DN50 Blind Flange is engineered for ease of installation and exceptional sealing effectiveness, making it a versatile choice for a wide range of industrial applications.

Chemical requirements
	N	C	H	Fe	O	Al	V	Pd	Mo	Ni	Ti
Gr1	0.03	0.08	0.015	0.20	0.18	/	/	/	/	/	bal
Gr2	0.03	0.08	0.015	0.30	0.25	/	/	/	/	/	bal
Gr5	0.05	0.08	0.015	0.40	0.20	5.5~6.75	3.5~4.5	/	/	/	bal
Gr7	0.03	0.08	0.015	0.30	0.25	/	/	0.12~0.25	/	/	bal
Gr12	0.03	0.08	0.015	0.30	0.25	/	/	/	0.2~0.4	0.6~0.9	bal

Tensile requirements
Grade	Tensile srength(min)		Yeild strength(mm)		Elongation(%)
	KSI	MPa	Ksi	MPa
1	35	240	20	138	24
2	50	345	40	275	20
5	130	895	120	828	10
7	50	345	40	275	20
12	70	438	50	345	18
