Titanium Sheet
Created with Pixso.

Fixation Of Fracture Medical Titanium Sheet

Fixation Of Fracture Medical Titanium Sheet

Brand Name: LHTi
Model Number: Titanium Sheet
MOQ: 50 kg
Payment Terms: T/T, MoneyGram, L/C, Western Union
Supply Ability: 200000 kg per month
Detail Information
Place of Origin:
China
Certification:
ISO9001:2015; TUV; SGS;BV
Standard:
ASTM B265
Technology:
Cold Rolled
Shape:
Square
Surface:
Polished, Acid Washing
Packaging Details:
Plywood box with soft foam for additional protection
Supply Ability:
200000 kg per month
Product Description

Fixation Of Fracture Medical Titanium Sheet



The Titanium Sheet For Fixation of Fracture produced by our company have strict quality control systems in terms of production and inspection. The mechanical properties, metallographic structure, tolerances, and ovality of the products are in full compliance with GB/T 13810-2007, ASTM F136, ASTM F67 standard. At the same time, before all products shipped from the factory, our company must pass ultrasonic inspection (to ensure that there are no internal defects in the product), and commission a third-party inspection (chemical composition, mechanical properties, high-magnification structure), and issue a test report to fully guarantee that no unqualified products leave the factory. , To safeguard the interests of customers and the lives of the people.



Chemical requirements
  N C H Fe O Al V Pd Mo Ni Ti
Gr1 0.03 0.08 0.015 0.20 0.18 / / / / / bal
Gr2 0.03 0.08 0.015 0.30 0.25 / / / / / bal
Gr5 0.05 0.08 0.015 0.40 0.20 5.5~6.75 3.5~4.5 / / / bal
Gr7 0.03 0.08 0.015 0.30 0.25 / / 0.12~0.25 / / bal
Gr12 0.03 0.08 0.015 0.30 0.25 / / / 0.2~0.4 0.6~0.9 bal



Tensile requirements
Grade Tensile srength(min) Yeild strength(mm) Elongation(%)
  KSI MPa Ksi MPa
1 35 240 20 138 24
2 50 345 40 275 20
5 130 895 120 828 10
7 50 345 40 275 20
12 70 438 50 345 18
