ASME B16.5 Class 150 Titanium Weld Neck Flange with Raised Face and Forged Construction

Brand Name:	LHTi
Model Number:	WN
MOQ:	1 pc
Price:	$35-258 / pc
Payment Terms:	L/C,T/T,D/P,D/A,Western Union
Supply Ability:	100000 pcs per month

Detail Information

Product Description

Detail Information

Place of Origin:

China , Shaanxi , Baoji(The titanium valley of China)

Certification:

ISO9001:2015

Material:

Titanium Gr2 Gr5 Gr7

Type:

WN (weld Neck Flange)

Standard:

ASME/ASTM B16.5

Size:

1/2''~80"

Class:

Class 150 Class 300 Class 600 Class 900 Class 1500

Quality Test:

UT,PT Etc.

MOQ:

1PC

The Third Party Test:

TUV,SGS,BV Etc.

Product Name:

ASME 16.5 B381 Ti Gr. 2 Titanium Weld Neck Flange Rf Class150 WN Forged Flange

Packaging Details:

Standard exporting packing: protecting foam and EPE inside and plywood case outside.

Supply Ability:

100000 pcs per month

Highlight:

ASME 16.5 B381 Weld Neck Flange

Class 150 WN Forged Flange

Forged Weld Neck Flange

Product Description

ASME 16.5 B381 Ti Gr. 2 Titanium Weld Neck Flange RF Class 150 WN Forged Flange

Product Description

High-quality ASME 16.5 B381 Ti Gr. 2 titanium weld neck flange with RF (Raised Face) Class 150 WN (Weld Neck) forged construction for superior performance in demanding industrial applications.

Key Specifications

Material: Available in Gr1, Gr2, Gr5, Gr7, Gr12 titanium grades
Standard: Compliant with ANSI B16.5, ASME B16.5, EN1092-1, JIS B2220, DIN2627-2628
Size Range: 1/2" to 30" NB (NPS 1/2 - NPS 24 / DN 10 - 2000)
Pressure Class: PN0.25~32Mpa (DIN) including PN6-PN250 and 150LB-2500LB
Sealing Surface: RF (Raised Face), FF (Flat Face), TG (Tongue & Groove), RJ (Ring Joint)
Manufacturing Technique: Precision forged and CNC machined

Functional Benefits

Forms a detachable connection when combined with gasket and bolts for versatile installation
Essential component for secure pipeline construction and maintenance
Designed for ease of use while capable of withstanding high pressure conditions

Titanium Grade Specifications

Grade	Tensile Strength (min)	Yield Strength (min)	Elongation (%)
Gr1 (Ta1)	35 ksi / 240 MPa	20 ksi / 138 MPa	24
Gr2 (Ta2)	50 ksi / 345 MPa	40 ksi / 275 MPa	20
Gr5 (Ti6Al4V)	130 ksi / 895 MPa	120 ksi / 828 MPa	10
Gr7 (Ti-0.2Pd)	50 ksi / 345 MPa	40 ksi / 275 MPa	20
Gr9 (Ti-3Al-2.5V)	90 ksi / 620 MPa	70 ksi / 483 MPa	15
Gr12 (Ti-0.3Mo-0.8Ni)	70 ksi / 483 MPa	50 ksi / 345 MPa	18
