Home > products > Weld Neck Flange > ASME 16.5 B381 Ti Gr. 2 Titanium Weld Neck Flange Rf Class 150 WN Forged Flange

ASME 16.5 B381 Ti Gr. 2 Titanium Weld Neck Flange Rf Class 150 WN Forged Flange

Product Details

Place of Origin: China , Shaanxi , Baoji(The titanium valley of China)

Brand Name: LHTi

Certification: ISO9001:2015

Model Number: WN

Payment & Shipping Terms

Minimum Order Quantity: 1 pc

Price: $35-258 / pc

Packaging Details: Standard exporting packing: protecting foam and EPE inside and plywood case outside.

Delivery Time: 10-15 days

Payment Terms: L/C, T/T, D/P,D/A,Western Union

Supply Ability: 100000 pcs per month

Get Best Price
Highlight:

ASME 16.5 B381 Weld Neck Flange

,

Class 150 WN Forged Flange

,

Forged Weld Neck Flange

Material:
Titanium Gr2 Gr5 Gr7
Type:
WN (weld Neck Flange)
Standard:
ASME/ASTM B16.5
Size:
1/2''~80"
Class:
Class 150 Class 300 Class 600 Class 900 Class 1500
Quality Test:
UT,PT Etc.
MOQ:
1PC
The Third Party Test:
TUV,SGS,BV Etc.
Product Name:
ASME 16.5 B381 Ti Gr. 2 Titanium Weld Neck Flange Rf Class150 WN Forged Flange
Material:
Titanium Gr2 Gr5 Gr7
Type:
WN (weld Neck Flange)
Standard:
ASME/ASTM B16.5
Size:
1/2''~80"
Class:
Class 150 Class 300 Class 600 Class 900 Class 1500
Quality Test:
UT,PT Etc.
MOQ:
1PC
The Third Party Test:
TUV,SGS,BV Etc.
Product Name:
ASME 16.5 B381 Ti Gr. 2 Titanium Weld Neck Flange Rf Class150 WN Forged Flange
ASME 16.5 B381 Ti Gr. 2 Titanium Weld Neck Flange Rf Class 150 WN Forged Flange



ASME 16.5 B381 Ti Gr. 2 titanium weld neck flange rf class150 WN forged flange



Welding Neck Flanges



Product Information



Material: Gr1, Gr2, Gr5, Gr7, Gr12

Standard: ANSI B16.5, ASME B16.5, EN1092-1, JIS B2220, DIN2627-2628

Size: 1/2"~ 30"NB, NPS 1/2 - NPS 24 (DN 10 - 2000) .

Pressure Clase: PN0.25~32Mpa/ (DIN) PN6,PN10,PN16,PN25 though PN250/ 150LB, 250LB ,300LB, 400 LB,500LB, 600 LB,900LB, 1500LB,2500LB.

Sealing Surface: RF, FF, TG, RJ etc.

Technique: Froged and CNC Machined



Functions



1. Flange, gasket and bolts are connected to each other as a detachable connection of a combined sealing structures.

2. Flange connection is an important connection method for pipeline construction.

3. The flange connection is easy to use and can withstand large pressures.



Different Titanium Grade



grade Tensile strength(min) Yeild strength(min) Elongation(%)
component ksi MPa ksi MPa
Gr1 Ta1 35 240 20 138 24
Gr2 Ta2 50 345 40 275 20
Gr5 Ti6Al4V 130 895 120 828 10
Gr7 Ti-0.2Pd 50 345 40 275 20
Gr9 Ti-3Al-2.5V 90 620 70 483 15
Gr12 Ti-0.3Mo-0.8Ni 70 483 50 345 18



Detailed Images



ASME B16.5 Titanium Weld Neck Flange

ASME B16.5 Titanium Weld Neck FlangeASME B16.5 Titanium Weld Neck Flange



Applications



Welding Neck Flanges



Production Process



ASME B16.5 Titanium Weld Neck Flange



Our Factory



ASME B16.5 Titanium Weld Neck Flange



Stock



Titanium Weld Neck Flange



Quality Inspection



ASME B16.5 Titanium Weld Neck Flange



Packaging
