| Place of Origin: | Baoji, China |
|---|---|
| Brand Name: | LIHUA |
| Certification: | ISO9001, TUV etc. |
| Model Number: | LH-WN |
| Minimum Order Quantity: | 5 Pieces |
| Price: | US dollar $25/pc--US dollar $85/pc |
| Packaging Details: | Wrapped by foam contained in plywood box for export |
| Delivery Time: | 3-15 Working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 50000 pcs per month |
| Product Name: | ASTM Titanium Flange | Standard: | ASTM/ASME B16.5 |
|---|---|---|---|
| Material: | Gr1, Gr2, Gr5, Gr7, Gr12 | Application: | Chemical Industry |
| Sealing Surface: | RF, FF, TG, RJ Etc. | Size: | NPS 1/2 - NPS 24(DN 10 - 2000) |
| Pressure: | 150#-2500# | Surface: | Polished |
| Technique: | Forged And CNC Machined | Inspection: | Ultrasonic Testing & Material Test Report EN10204.3.1 |
| High Light: | Gr12 Titanium Weld Neck Flange,Chemical Industry Titanium Weld Neck Flange,PolishedWeld Neck Pipe Flanges |
||
ASTM Standard Titanium Flange
1. Application:For seal or connect of pipe/tube lines
2. Material:Gr1 Gr2 Gr5 Gr7 Gr12
3. Standard: ASTM B16.5 / ANSI B1.65 / ASME B16.5
4. Size:1.2" to 200" (DN15 to DN5000)
5. Type:Weld neck flange, Slip on flange, Threaded Flanges, Socket Welding Flanges, Blind Flange, could be customized by customer's drawings
Different Type flanges' Specification
Welding neck flange:
1, Preferable for high-pressure, subzero or elevated temperature
2, Hub is tapered and bored to match pipe's inner diameter so flow is not restricted, preventing turbulence and reducing erosion
3, Easily radiographed and provides excellent stress distribution
Slip on flange:
1, Not normally used in high-stress applications due to low hub and weld attachment
2, Silps over outside of pipe
3, Inside of flange welded at hub and end of pipe
Lap joint flange:
1, Used where bolt alignment or access for cleaning is required
2, Similar to slip-on flange when used with lap joint stub end
3, Radius at intersection of flange face and bore to match lap joint stub end
Socket welding flange:
1, For small-diameter chemical processes, hydraulic and stream distribution lines
2, Similar to slip-on flange
3, Counter bore matches pipe bore, allowing unrestricted flow
4, Counter bore from hub side fits pipe's outer diameter - can insert pipe in socket with fillet weld at hub
Blind flange:
1, Used to close ends of piping
2, Has no bore
3, Permits access to sealed lines
Other flanges:
Orifice, Expander, Reducing, Lightweight, Studding Outlets, Long Weld Necks,Metric, Navy Drawings, Customer Drawings
Applications
Production Process
Our Factory
Stock
Quality Inspection
Packaging
Any Requests you can contact us for catalogues. Thanks.
