Technique: | Forged, CNC Machning | Surface Finish: | Polished |
---|---|---|---|
Application: | Petrochemical Industry, Medical | Grade: | Pure Titanium And Titanium Alloy |
High Light: | forged titanium ring,titanium forged ring |
name | Grade | Specifications(mm) | ||||
Outer diameter | Inner diameter | Section Height | Ring material thickness | |||
GR1 GR2 GR5 GR7 GR12 | ||||||
Titanium Ring | 200--400 | 100-300 | 35-120 | 40-150 | ||
>400--700 | 150-500 | 40-160 | 40-250 | |||
>700--900 | 300-700 | 50-180 | 40-300 | |||
>900--1300 | 400-900 | 70-250 | 40-400 |
Titanium is more then 46% lighter than steel. For comparative analysis, aluminum is approximately 0.12 lbs/cu.in, Steel is approximately 0.29 lbs/cu.in, and Titanium is approximately 0.16 lbs/cu.in.
Low modulus, high fracture toughness and fatigue resistance,
Suitability for coiling and laying on seabed,
Ability to withstand hot/dry and cold/wet acid gas loading,
Excellent resistance to corrosive and erosive action of high-temperature acid steam and brine,
Good workability and weldability.
