ASME B16.5 Class 300 Titanium Slip On Flange with Raised Face

Brand Name:	LHTi
MOQ:	100 pieces
Price:	negotiable
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	200 Ton/Tons Per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Baoji, China

Certification:

ISO9001,CE,etc

Face Type:

Raised Face, Flat Face, Ring Type Joint

Unit Price:

$25usd/pc-$85usd/pc

Flange Facing:

RF, FF, RTJ

Design:

ASME B16.34

Technology:

Colding Forming ,hot Working And Welding

Grades:

Gr2, Gr5, Gr7, Gr12

Size:

1/2 Inch - 24 Inch

Nominal Diameter:

DN15-DN1000 1/2

Packaging Details:

Plywood case or pallet, or as per your requirement

Supply Ability:

200 Ton/Tons Per Month

Highlight:

ASME Slip On Flange

SORF Raised Face Slip On Flange

Product Description

ASME B16.5 Class 300 Titanium Slip On Flange with Raised Face

The ASME B16.5 Titanium Slip-On Flange (SORF) Gr1, Gr2, Gr5 Class 300 is engineered for demanding oil and gas applications, offering superior performance in critical pipeline systems.

Key Features

Material Grades

Gr1 (Grade 1 Titanium): Commercially pure titanium offering exceptional corrosion resistance, ideal for environments requiring maximum chemical resistance.
Gr2 (Grade 2 Titanium): The industry standard grade providing optimal balance between corrosion resistance and mechanical strength for diverse applications.
Gr5 (Grade 5 Titanium - Ti6Al4V): High-strength alloy containing 6% aluminum and 4% vanadium, designed for extreme temperature and pressure conditions in demanding environments.

Technical Specifications

Class 300 Pressure Rating: Withstands pressures up to 300 psi at room temperature, ensuring reliable performance in standard pipeline systems.
Slip-On Flange Design (SORF): Engineered to fit over pipe ends with interior and exterior welding for enhanced structural integrity and simplified installation.
Raised Face (RF): Precision-machined raised sealing surface ensures optimal gasket compression and leak-free connections in critical applications.

Performance Benefits

Benefit	Technical Advantage
Corrosion Resistance	Superior resistance to corrosive elements including saltwater, chemicals, and harsh environmental conditions
Strength-to-Weight Ratio	Exceptional mechanical strength combined with lightweight properties for efficient system design
Extended Service Life	Inherent resistance to corrosion, erosion, and chemical degradation ensures long-term reliability
Simplified Installation	Slip-on design facilitates quick alignment and welding, reducing assembly time and labor costs
Leak Prevention	Raised face design provides superior sealing performance for critical containment applications

Industrial Applications

Oil and Gas Systems

Offshore drilling platforms and subsea installations
Pipeline transmission systems and distribution networks
Refinery processing units and chemical plants
Production facilities and wellhead equipment

Specialized Environments

Marine and coastal installations with saltwater exposure
High-temperature and high-pressure processing systems
Corrosive fluid handling and chemical transfer applications

Technical Summary

The ASME B16.5 Titanium Slip-On Flange Gr1, Gr2, Gr5 Class 300 with raised face represents the pinnacle of reliability for oil and gas applications. Engineered to withstand extreme conditions while maintaining structural integrity, these flanges provide unmatched corrosion resistance, durability, and sealing performance for critical pipeline infrastructure.
