Gr5 Gr9 Pure Ti Titanium Alloy Balls 12mm Connection Type Threaded

Name: Gr5 Gr9 Pure Ti Titanium Alloy Balls 12mm Connection Type Threaded
Brand: Baoji Lihua Nonferrous Metals Co., Ltd.
SKU: Titanium Ball
Price: 22,899.08 USD
Availability: InStock

Brand Name:	LHTi
Model Number:	Titanium Ball
MOQ:	10 pieces
Price:	negotiable
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	5000 Pieces Per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Baoji, China

Certification:

ISO9001,CE,etc

End Connections:

Flanged (ANSI, JIS, DIN, GB)

Pressure Rating:

Class 150-2500

Sealing Method:

Floating Ball, Trunnion Mounted

Top Entry Design:

Available

Surface Treatment:

Polished Mirror Bright

Ball Material:

Titanium, Stainless Steel

Actuator Type:

Manual, Pneumatic, Electric

Applications:

Water Gas Steam, Industrial Applications

Type:

Ball Valve

Port Rating:

ASME Class 150, Flanged Ends

Packaging Details:

Plywood case or pallet, or as per your requirement

Supply Ability:

5000 Pieces Per Month

Highlight:

Body Jewerly Titanium Alloy Balls

12mm Titanium Alloy Balls

Bearing Titanium Alloy Balls

Product Description

Gr5 Gr9 Pure Ti Titanium Alloy Balls 12mm Connection Type Threaded

Precision-engineered titanium alloy balls manufactured to exacting standards for demanding industrial applications requiring exceptional strength, corrosion resistance, and lightweight properties.

Titanium Ball Properties

Corrosion Resistance

Exceptional resistance to corrosion in aggressive environments including seawater and chemical processing plants, ensuring long-term durability and reliability.

Lightweight Construction

Low density provides significant weight reduction compared to steel while maintaining comparable strength, ideal for aerospace and automotive applications.

High Strength Performance

Excellent strength-to-weight ratio capable of withstanding high loads and pressures in demanding mechanical applications.

Biocompatibility

Non-toxic and biocompatible properties make these balls suitable for medical implants, surgical instruments, and dental applications.

Thermal Stability

Maintains mechanical properties across wide temperature ranges from cryogenic to moderately high temperatures.

Product Specifications

Product Name	Making titanium ball for bearing/jewelry
Available Grades	Gr1, Gr2, Gr5 (Ti-6Al-4V), Gr23, Ti-3Al-2.5V
Origin	Wuxi
Titanium Content	≥99.6%
Impurity Content	<0.02%
Density	4.51 g/cm³
Color	Titanium natural color or custom coated colors
Available Types	Drilling, threading, brushing, polishing, plating, coating
Size Range	Diameter 0.5-300mm, custom sizes available
Manufacturing Technique	Machining, Forging
Applications	Body Jewelry, Medical Applications, Calibration Metrology, Chemistry

Chemical Composition

Titanium Grade 5 (Ti-6Al-4V)

Element	Content (%)
Fe	≤0.30
C	≤0.10
N	≤0.05
H	≤0.015
O	≤0.20
Al	5.50-6.80
V	3.50-4.50
Ti	Balance

Titanium Grade GR7

Element	Content (%)
Ti	Balance
N	≤0.03
C	≤0.08
H	≤0.013
Fe	≤0.25
O	≤0.15

Grade 5 vs Grade 9 Titanium Comparison

Grade 5 Titanium (Ti-6Al-4V)

Composed of approximately 90% titanium with 6% aluminum and 4% vanadium. This high-strength alloy offers exceptional strength-to-weight ratio, excellent corrosion resistance, and maintains mechanical properties at elevated temperatures. Ideal for aerospace components, medical implants, and high-performance equipment.

Grade 9 Titanium (Ti-3Al-2.5V)

Contains approximately 92.5% titanium with 3% aluminum and 2.5% vanadium. Provides balanced strength and formability with excellent corrosion resistance and superior weldability compared to Grade 5. Suitable for marine applications, bicycle frames, and industrial equipment.

Key Differences

Composition: Grade 5 has higher aluminum and vanadium content than Grade 9
Strength: Grade 5 offers superior mechanical strength
Weldability: Grade 9 provides better welding characteristics
Applications: Grade 5 for high-performance aerospace, Grade 9 for marine and welded structures

Application Areas

Grade 5 Titanium Balls Applications

Aerospace Components: Bearings and valve components requiring high strength and corrosion resistance
Medical Applications: Surgical implants, artificial joints, and dental implants
High-Performance Equipment: Racing bicycles, golf clubs, and precision sports equipment
Industrial Applications: Precision instruments and measuring devices

Grade 9 Titanium Balls Applications

Marine Applications: Underwater bearings and marine rotary equipment
General Industrial Use: Pumps, valves, and flow control devices
Sporting Goods: Bicycle bearings and sports equipment components
Chemical Processing: Mixing and stirring applications in corrosive environments
