0.1mm 0.3mm Titanium Alloy Welding Wire Gr1

Name: 0.1mm 0.3mm Titanium Alloy Welding Wire Gr1
Brand: Baoji Lihua Nonferrous Metals Co., Ltd.
SKU: Titanium wire
Price: 22.00 USD
Availability: InStock

Brand Name:	LHTi
Model Number:	Titanium wire
MOQ:	20 kg
Price:	USD16.00-28.00 per kg
Payment Terms:	T/T,,L/C,Western Union,Paypal
Supply Ability:	200000 kg per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001:2015; TUV; SGS;BV

Material:

Factory Direct-Sales Gr1 Gr2 Pure Titanium Wire For Welding AWS A5.16 Titanium Spool Wire

Grade:

Gr1, Gr2

Diameter:

0.5mm-3mm

Straight Wire Length:

1000mm-3000mm

MOQ:

20 Kg

Package Box:

5kg Per Plastic Box, Or As Your Request

Certificate:

ISO9001:2008

Processing Service:

Bending, Cutting

Package Coil:

10~15kg ,or As Per Buyer Requirement

Advantage:

Corrosion Resistance, High Strength, Light Quality

Packaging Details:

Plastic bag with laber, outside plastic box, then plywod box

Supply Ability:

200000 kg per month

Highlight:

0.3mm Titanium Alloy Wire

Titanium Alloy Wire Corrosion Resistance

Gr1 Titanium Wire

Product Description

0.1mm 0.3mm Titanium Alloy Welding Wire Gr1

This titanium alloy welding wire is produced in Gr1 and Gr2 to AWS A5.16 and supplied in annealed or processing states. It is available as straight wire, spool or coil with diameters from 0.5 mm to 4.0 mm, and it offers corrosion resistance, high strength and low weight for titanium welding and fabrication work.

Titanium Alloy Welding Wire

Technical Specifications

Standard	AWS A5.16
Material	Pure titanium
Grade	Gr1, Gr2
Diameter	0.5 - 4.0 mm
Straight Wire Length	1000 - 3000 mm
Condition	M (annealed soft), R (processing soft), Y (processing hard), D (nitinol memory training)
Processing Service	Bending, cutting
Advantage	Corrosion resistance, high strength, light weight

Available Diameters & Forms

Diameter (mm)	Diameter (inch)	Straight	Spool	Coil
0.5	0.020	Yes	Yes	Yes
0.8	0.031	Yes	Yes	Yes
1.0	0.039	Yes	Yes	Yes
1.6	0.062	Yes	Yes	Yes
2.0	0.079	Yes	Yes	Yes
3.0	0.118	Yes	Yes	Yes
4.0	0.157	Yes	Yes	Yes

Filler Metal Selection Guide

Base Metal Grade	Normal Composition	Recommended Filler	UTS min (MPa)	YS min (MPa)
Grade 1	Unalloyed Ti CP1	ERTi-1	240	138
Grade 2	Unalloyed Ti CP2	ERTi-2	345	275
Grade 4	Unalloyed Ti CP4	ERTi-4	550	483
Grade 5	Ti 6Al-4V	ERTi-5	895	828
Grade 7	Ti 0.15Pd	ERTi-7	345	275

Applications & Titanium Advantages

Gr1 and Gr2 wire are used for industrial corrosion service and for welding pressure vessels, columns, tanks, heat exchangers, shafts, blowers, condenser tubing, valves, fittings and pipe. Grade 1 is chosen where ductility matters most, such as explosive cladding and deep drawing, while Grade 2 is the most common unalloyed grade for process equipment. Titanium resists chlorides and oxidising media and keeps a stable passive film, so welded joints last in demanding environments.

Quality, Customization & Inquiry

Wire is produced under an ISO 9001 quality system with TUV, SGS and BV certification available, and bending and cutting services can be supplied. Packing is a plastic bag or soft paper inside a wooden case. Please send your specification and quantity for a quotation.
